Vertical stainless mixer tank
- 150 Piece / Pieces per Month
- ningbo
- T/T
Product Details
Condition: | New | Mixer Type: | Paddle | Product Type: | Detergent Powder |
Application: | Liquid with Suspended Solids | Additional Capabilities: | Granulating | Place of Origin: | Zhejiang, China |
Brand Name: | DF | Model Number: | ZJ-DF-05 | Max. Loading Capacity: | 5000L |
Voltage: | 220V/380V | Power(W): | 0.75KW~45KW | Dimension(L*W*H): | 500*500*5~3000*3800*12 |
Certification: | ISO9001 | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Mixing tank is tank with an agitator.It is mainly used for mixing or blending.A jacket can also be equiped for heating.
Mixing tank(also called blending tank) is maily used in food, beverage and chemical industries,it is made of stainless steel SUS304 or SUS304. Inner shell is specular-polished and rotation mechanism polishing.
(Also can be Side mixers at a shape you like!)
Advantage:
- Outer casing surface:Mirror polishing/2B original sub-gloss/2B frosted sub-gloss
Inner surface:Mirror polishing(Roughness:Ra<0.4um) - Liquid level gauge:optional.
- Thermometer:optional.Temperature indication ranges from 0 to 100oC
- Sample valve equipped
- Agitation device:Paddle,Anchor,or spiral agitator(optional)
- .Cip cleaning:T-shaped 360o rotational CIP cleaning ball
- Man-hole equipped
Main Tech Parameters:
Parameter | LP 300 | LP400 | LP500 | LP600 | LP1000 | LP2000 | LP3000 | LP5000 | LP10000 | |
Cubage(L) | 300 | 400 | 500 | 600 | 1000 | 2000 | 3000 | 5000 | 10000 | |
Pressure | Internal bladder | ≤ 0.2Mpa | ||||||||
Insert set | ≤ 0.3Mpa | |||||||||
Power (Kw) | 0.55 | 0.55 | 0.75 | 0.75 | 1.1 | 1.5 | 1.5 | 2.2 | 3 | |
Speed of impeller | 18=200r/min | |||||||||
Outlook size | Diameter | 900 | 1000 | 1150 | 1150 | 1400 | 1580 | 1800 | 2050 | 2500 |
Height | 2200 | 2220 | 2400 | 2500 | 2700 | 3300 | 3600 | 4200 | 5000 | |
Heat transfer area | 2 | 2.4 | 2.7 | 3.1 | 4.5 | 7.5 | 8.6 | 10.4 | 20.2 |
We are warmly welcome yours any inquiry!
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
Shipment
Bulk cargo: standard wooden case which can avoid any clash during the sea or air transportation in case of causing damage to the equipment’s surface.
Container cargo: equipment will be bound firmly,won’t easily swing to the side, or up, or down.
