Introduction:
The cooling jacket adopts the form of honey comb jacket.
The jackets are provided at tank body and conical bottom to effectively increase the cooling speed. heat exchanging area of jacket of different proportions can be allocated according to customers' technological requirements.
Adopted the international standards of fermentation technology, diverse methods to control the temperature, the inner surface of the tank are mirror-polished. Completely meet the demanding of PLC and sterilize system.
This product is widely used in such industries as brewing, dairy product processing etc.
The Conical Fermenter is a beautifully designed product for the discriminating brewer.Its features provide commercial brewery functionality at a consumer good price. It is easy to use and load with standard features. Clearly the best and only way to siphon clear beer or wine!
Key Specifications/Special Features:
- Material: 304-2B stainless steel
- Isolation: PU foam
- Capacity: 200 to 20,000L
- Dimple pad cooling jacket in the tank body and conical bottom, efficiently cools the tank in all parts
- Cooling exchange areas are available in different designs
- Conical bottom in 60 degrees is designed for the yeast fermentation processing
- Configure: CIP socket,sideway manhole,strong leg supports, temperature gauge and sampling socket
- Applications: winery, brewery storage and fermentation
Volume | 300L | 400L | 500L | 600L | 800L | 1000L | 1500L | 2000L | 3000L |
Body diameter(mm) | Φ800 | Φ800 | Φ900 | Φ1000 | Φ1000 | Φ1000 | Φ1200 | Φ1300 | Φ1600 |
Body height(mm) | 600 | 800 | 800 | 800 | 1000 | 1220 | 1220 | 1500 | 1500 |
Motor power(kw) | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 1.5 | 2.2 | 3 |
Working pressure | ≤0.09Mpa | ||||||||
Working temperature | <100°C | ||||||||
Accessories | Sanitary manhole, air breath hole, CIP automatic cleaning ball, safety sample valve, , outlet valve, pressure gauge ,normal thermometer(0-150 degree)
| ||||||||
Our company’s advantages over other companies:
Advanced Technology Co., Ltd Wenzhou is the a professional Stainless steel Mixing Equipment,Tank Pressure Vessels,Filters,Beer equipment and brewing technology supplier, who can professionally design, research and develop, and manufacture these equipment.
We can provide clients one-stop service from design, layout, to finished products. Its main business includes beer equipment, self brewing equipment, hotel beer equipment, draft beer dispenser, school laboratory equipment, etc. We mainly provide the capacity 500L/DF, 1000L/DF, 2000L/DF, 3000L/DF, 5000L/D,10000L/D,20000L/D etc.
Our staff of Sales and Technical Support is available to help you in selecting the right protection for your application as well as to provide you with Samples of our products for evaluation. At Advanced Tech., we are committed to providing the Highest level of customer service, Competitive pricing, Speedy delivery and a Comprehensive, cutting-edge product offering. Our ultimate goal is your satisfaction.
Our company’s quality certification:
We have got CE, PED, ISO9001 (2008) certificates. If necessary, we can offer electronic record’s certificates but the original document must be kept in the company.
Our company’s customer segmentation:
Our customer segmentation is mainly focused on the European,American developed countries such as the USA,Canada, Lati-America,the United Kingdom, Australia,
Saudi Arab and Asia etc. At present,we are looking for superior agents to create a brilliant future.
