Micro Brewery Equipment for Good Price

Name: Micro Brewery Equipment for Good Price
Brand: DAFENG
SKU: 141360664
Availability: InStock

US$ 500 - 5,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

DAFENG

Advanced Tech. Co., Ltd. Wenzhou

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo/shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name DAFENG

Model Number DF-FT

Processing Types Other, beer

Voltage customized

Power(W) customized

Dimension(L*W*H) made-custom

Weight made-custom

Certification CE

Warranty 3 years

After-sales Service Provided Engineers available to service machinery overseas

Micro brewery equipment for good prices

brewery machine used for beer fermenter

DESCRIPTION

Our company make from Microbrew to small,medium size plant.

Sometimes they are custom-made to meet special requirements.

1. PRODUCT INFORMATION

A whole set of 1000L brewery equipment basically including below parts:

Main equipments	1	Mash/lauter tank	1000L	1 PC
Saccharification	2	Boiling/whirlpool tank	1000L	1 PC
	3	Hot water tank	1000L	1 PC
	4	Wort pump	1/3T/h	1PC
	5	Malt miller	100/300Kgs/h	1 PC
	6	Mash pipelines	S.S.304	Assorted
Fermentation	1	Fermentation tanks&Bright Beer tanks	1000L/2000L	4PCS
Cooling	1	Ice water tank/Hot liquor tank	4000L	1 PC
	2	refrigerator machine	8P	1 PC
	3	Heat exchanger	8m²	1 PC
Control	1	Control cabinet for mashing,chilling,fermenting		Assorted
CIP UNIT	1	Sterilizer tank	100L	1 PC
	2	Caustic soda tank	100L	1 PC
	3	Transfer pump	3/T/h	1 PC

2. TECHNICAL SPECIFICATION

Outside surface	S.S.304,THK:1.5mm-3mm
Inner surface	S.S.304,THK:2mm-4mm
Top shape	Seal head or conical head
Heating method	Natural gas/electricity/direct fire
Insulation layer	Protected by rockwool,THK:70-100mm
Polishing precision	≤0.28µm
Manhole	Side upward
Spral ball	In the center of the inside tank
Agitator	Raking system conneted into a top reducer
Chimney	On the top of the tank

Advantage & specification

We offers mature BREWHOUSE plants with sizes from 5hl to 10hl and annual capacities from 250hl and 3000hl.
Adopted international standards of fermentation technology, high cooling efficiency, being heated evenly, short cooling time.
Inner layer is made up of Acid-resistant and therMal proof, austenitic stainless steel,beautiful figure, easy installation, simple operation, on the safe side.
The internal surface adopts mirror polishing until Ra≤0.28μm, and the external surface adopts polishing, mirror polishing, sandblasting or cold rolling original.
Their features provide commerical brewery functionality at a brewing buget,which are also available as industrial plants or Restaurant Breweries.
Breweries export to the entire world market and modifies these plants to the needs of the specificregion in terms of climate and infrastructure.
Sanitation grade can even according to GMP.
