System Characteristics
1.The treatment head of E-light mainly combined with three parts: bipolar radio frequency+low-energy pulse light energy+epidermal cooling.
2.Treatment result is obviously enhanced on clinic,and the various skin problems like wrinkle and telangiectasia are greatly improved.
3.Multi-features of E-light machine lead to the machine as the best choice for patient:comfortable treatment,better effect,faster results and minimal side effects,etc.
4.Adapting to the wider population,safe to all kinds of skin types,it also can be used for the treatment of skin Type IV and skin type V.
5.Easy operation,you only need to adjust the energy of IPL and RF individually.
6.Pre-cooling to the epidermis,this can result in temperature difference between epidermis and dermis,the energy lunched by RF act on the pre-warmed aimed-tissue(such as veins,hair follicles,melanin,etc.),so as to achieve the best RF penetration effect.
normal temperature cooling IPL devices pump
You may interest product.....
|
|
|
|
|
1.Advanced magnetic driving technology for static-seal, without any leakage forever
2.Motor widely voltage designed suitable for battery power supplying with peak-low voltage damply
3.Durable permanent magnetic rotor with one-off injection incorporated impeller in smooth balance
4.Heavy duty work, can sustain continuous 24 hours work
5.Special designed high efficiency closed-type impeller
6.Sustain 100°C hot water circulation
7 FDA approved to be safety usage
8.Low or no maintenance
9.Blocked protection
10.Polarity protection
| Model | Rated Voltage (V) | Work Voltage Range (V) | Current (A) | Power (W) | Max flow rate (L/min) | Max water head (M) |
| TL-B10-A12-0703 | 12 | 6~14 | 0.6 | 7 | 7 | 3 |
| TL-B10-A12-0905 | 12 | 6~14 | 1.4 | 16.8 | 9 | 5 |
| TL-B10-B12-0703 | 12 | 6~14 | 0.6 | 7 | 7 | 3 |
| TL-B10-B12-0905 | 12 | 6~14 | 1.4 | 16.8 | 9 | 5 |
| TL-B10-A24-0703 | 24 | 12~26 | 0.4 | 10 | 7 | 3 |
| TL-B10-A24-0905 | 24 | 12~26 | 0.6 | 15 | 9 | 5 |
| TL-B10-A24-1208 | 24 | 12~26 | 1.3 | 31.2 | 12 | 8 |
| TL-B10-B24-0703 | 24 | 12~26 | 0.4 | 10 | 7 | 3 |
| TL-B10-B24-0905 | 24 | 12~26 | 0.6 | 15 | 9 | 5 |
| TL-B10-B24-1208 | 24 | 12~26 | 1.3 | 31.2 | 12 | 8 |
| Max Flow Rate | 7L/min 9L/MIN 12L/MIN |
| Max Static Lift | 3M 5 M 8 M |
| Rated Voltage | 12V / 24V |
| Impeller Type | Closed impeller |
| Motor Type | brushless DC motor |
| Liquid Temperature | 0-100°C |
| Pump Theory | Centrifugal pump |
| Ambient Temperature | -10-50°C |
| Media | Pure Water |
| Waterproof Class | IP42 or Submersible (optional) |
| Use Place | Indoor Outdoor |
| Working Voltage Range | 6~14V or 12~26V |
| Power Consumption | 1~31W |
| Noise Class form 1M | 40dB /Max |
| Ideal Life Time | 20000 Hours |
| Working Mode | Continuous |
| OD of Inlet | 18 mm |
| OD of Outlet | 10.8 mm |
| Dimension | 81.9x46.31x61.36 mm |
| Power Supply | DC power supply, battery, solar powered |
| Protection Functions | Blocked protection |
| Remarks | Can’t dry-running, not Self-priming |
|
customized functions
|
1.submersible lar panel driven directly |
|
The technical parameters above is only for your reference, for more details , please feel free to contact us. | |
What's IPL?
IPL is the abbreviation of intense pulsed light.
IPL is the kind of broad spectrum, varied wavelength with intense plused light. Which exposure to skin's surface directly, selective effect on subcutaneous abnormal pigment and abnormal vascular.It will abnormal pigment cell decomposition, close abnormal capillary. Meanwhile, intense pulsed light is to absorbed collagen moisture and to produce thermal effect. Finally stimulating the proliferation of collagen and made the rearrangment of collagenous tissue , achieving the purpose of skin rejuvenation,wrinkle removal and blood vessel removal.
Typical Applications
• •
• Automotive air conditioning • Carbonation, Coffee Maker, Beverage Dispenser • Air-conditioner Drain • Chillers, Cooling Circulation, • Home Appliance Boosting • Evaporative coolers
Brushess Mini DC water pumps work Note:
1. Power to DC Power Supply, reverse polarity is strictly prohibited, generally red positive power supply, black to negative
2. pumps in addition to immersible work can be identified, the rest can not be immersed in water, or they will cause a short circuit burned.
3. pumps is prohibited by the strong shock, fall from a height on the ground and other external damage.
4. pumps can not take strong acid and other corrosive liquids and granular solids with a tiny hard. Can not cycle more thick viscosity liquids, such as oil, high concentrations of oil and other fluids vast.
5. pumps was not long-time stall, causing the motor burned.
6. pumps can not withstand high voltage shock.
Customers how to choose the pump
1. first determine the voltage, current,water head and flow, diameter size, pump water head is generally the subject of the water does not flow when pumped up to the static head, if a customer requires pumping the water to a certain height and then to maintain a certain water flow, select the desired water head must be higher than the specified pumping height. This specific by the supplier according to the actual conditions. Can refer to lift flow graph.
2. to determine the dimension and form (threaded interface, inlet and outlet orientation, aperture size, etc.)
3. to determine the job requirements (temperature, medium, work time and frequency)
4. to determine the functional requirements (time control, pressure control, flow control, speed, etc.)
Applications of opt ipl shr hair removal machine
1. Skin rejuvenation and skin whitening for the whole body;
2. Stretch marks, forehead wrinkles, crow's feet, nasal furrow wrinkles, neck wrinkle;
3. Painless and permanent hair removal;
4. Freckle/chloasma/age pigment/sunburn/chorioplaque removal, eliminating chromatosis;
5. Anaphylatic pox, acne, acne scar, blackhead;
6. Red face, red blood streak, acne resacea, etc.
