Specifications
1. Good air permeability2. Dimensional Stability
3. Wear resistance
4. Easy cleaning
Product Description
Antistatic filters cloth (bag) is mainly directed against a number of fiber (especially synthetic) resistance, highly charged and design. Some e-change of gathering dust in the filter surface, the impact of the filter bag cleaning effect of increased resistance in a row, leading to the inside and outside the bag under high ignite flammable in the bag filter dust, dust concentration reaches a certain line when the explosion may occur.
At present, make filter material has the properties of electrical conductivity is:
(1)Of woven filter cloth interval in the warp yarn into the conductive.
(2)Acupuncture in the media warp in the fabric between conductive yarns into cloth.
(3)Acupuncture in the media web of conductive fibers mixed.
The technical data of antistic polyester needled felt
Article Name | Antistatic PET | Antistatic PET | Antistatic PET | |
Ingredients | Fiber | 100%PET | PET +Metal fiber | PET+ conductive fiber |
Scrim | PET + Metal fiber | 100%PET | 100%PET | |
Weight(g/m2) | 500 | 500 | 500 | |
Thickness(mm) | 1.7 | 1.7 | 1.7 | |
Density(g/m³) | 0.29 | 0.29 | 0.29 | |
Permeability | 130 | 130 | 130 | |
Tensile breaking | Warp | ≥1000 | ≥1200 | ≥1200 |
Weft | ≥1200 | ≥1500 | ≥1500 | |
Elongation | Warp | ≤5 | ≤5 | ≤5 |
Weft | ≤5 | ≤5 | ≤5 | |
Maximum | Temperature | 150 | 150 | 150 |
% | ≤1 | ≤1 | ≤1 | |
Service | Continuous | 130 | 130 | 130 |
Instant | 150 | 150 | 150 | |
Finishing | Heat setting, Singeing, calendaring | |||
Remarks | Surface resistance:< 10 2 Ωcm | |||
