Plastic Water Bag Filling Sealing Machine
1) Technical Features:
1. Adopts the man-machine conversation interface,PLC and the transducer communicating with each other to display and control the each functions and the running state, stable and reliable.
2. The Double channel temperature of the horizontal and vertical is controlled by intelligent temperature controlling device.
3. Intelligent photo cell orientation, transform discretionarily between the light/shade. Strongly anti-jamming, when two bags can’t catch up with the upper mark the machine will stop and give an alarm.
4. The packaging speed can be adjusted continuously within specified range. Orientation open mouth and stop.
5. The integrative cutter has a device of dustproof with it. It is very easy to adjust the cutter’s position.
6. The bag-making has high precision. Easily Operation and maintain.
7. Having functions just like paper cutting,bag-stopped up,safe door detecting and so on.
8. Measurement adopts adjustable cup method, which is accorded with the national measurement standard
2) Main functions for Plastic Water Bag Filling Sealing Machine
This machine is high precision packing machine and the most advanced liquid compound packing machine in China, which is standing, three sides sealing and intermittent. It can automatically complete Bag-making, filling, sealing, printing, cutting and counting .Controlled by microprocessor and automatic photocell.
- Plastic package forming
- UV disinfection
- With cursor
- Vertical seam sealing
- date synthesis
- Line traction plastic package
- Quantitative filling
3) Application for Plastic Water Bag Filling Sealing Machine:
It is widely used to pack all kinds of liquid without gas, especially soy, wine, vinegar, juice, soybean milk, peanut oil, vegetable oil, plant oil, mineral water and liquid chemical
4) Specification for Plastic Water Bag Filling Sealing Machine:
| Model No. | MA-DZN-1000 |
| Capacity | 1500-1800BAGS/H |
| Filing Range | 100-500ML |
| Film width: | 24cm or 32cm |
| Voltage | AC220V/50HZ AC380 |
| Main Motor Power | 370W |
| Machine size | 850×850×1730MM |
| Packing size | 1100*940*1930 MM |
| Weight | 400KG |
