Mineral Water Cup Filling And Sealing Machine

Mineral Water Cup Filling And Sealing Machine photo-1
Mineral Water Cup Filling And Sealing Machine photo-2
Mineral Water Cup Filling And Sealing Machine photo-3
Mineral Water Cup Filling And Sealing Machine photo-4
Mineral Water Cup Filling And Sealing Machine photo-5
Mineral Water Cup Filling And Sealing Machine photo-6
US$ 12,000 - 15,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Other, Cup
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Beverage
Packaging Type Other, Cup
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220v 380v
Power 5.5KW
Place of Origin Jiangsu, China
Brand Name Mars
Model Number BF-H4
Dimension(L*W*H) 3200x800x1850mm
Weight 700kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Mineral Water Cup Filling And Sealing Machine

I.Parameters

Parameter

BF-H6(Mode)

BF-H8(Mode)

BF-H24(Mode)

Range(G)

≤280

≤200

≤120

Capacity(Pcs/h)

4000-5000

9000-10000

22000-25000

Power(Kw)

5.5

8

10



Mineral Water Cup Filling And Sealing Machine



II.Function for Mineral Water Cup Filling And Sealing Machine

1. Beautiful, clean, brigh at shape of machine.
2. Made of stainless steel (except for the parts which connect with the materials) and meets the sanitation standards for foodstuff.
3. Uses air pressure to drive.
4. Complete function.
5. The whole process is completely automatic from container supplying, filling, sealing, leftover materialcutting, pruduct being moved out to leftover material receiving.
6. Can fill, seal and cut several containers at the same time.
7. Improve the production efficiency.
8. Has photoelectric eyes.
9. Can automatically correct the film sealing position and ensure the sealing position is right
10. Fitting for filing and sealing all kinds of liqid and products like paste, such as jelly, milk, ice cream, mineral water, jam, etc.



Mineral Water Cup Filling And Sealing Machine



III.Main Fittings for Mineral Water Cup Filling And Sealing Machine
1.Electric Fittings: Yatai PID Self-adjusting Automatic Temperature Control Meter, Schneider

Pushbutton, Selector Switches, Pilot Lights, Contactor and Thermal Overload Relay, Korea LG Circuit-breaker;
2.Lubricating System: Taiwan Famous Automatic Oiling System;
3.Pneumatic System: Japan SMC;
4.Hydraulic System:Guangye hydraulic the pump and Taiwan Lianton hydraulic the electromagnetism valve.

  Mineral Water Cup Filling And Sealing Machine



Please tell us the capacity you need, we will quote to you of matched model.
