Mineral Water Bottle Filling Machines
Automatic water bottle filling machine, Beverage pet bottle filling Machinery:
1. Using the wind sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottleneck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough..
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed large gravity flow valve filling valve, filling fast, filling accurate and no liquid lose.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Main Parameter for Mineral Water Bottle Filling Machines
Model |
CGF16126 |
CGF18186 |
CGF24248 |
CGF323212 |
Heads of washing,filling, sealing |
16-12-6 |
18-18-6 |
24-24-8 |
32-32-12 |
Production capacity |
3000-5000BPH |
6000-8000 |
8000-10000 |
10000-12000 |
Suitable bottle diameter |
φ=50-100mm, H=170mm, 330-2500ml |
φ=50-100mm, H=170mm, 330-2500ml |
φ=50-100mm, H=170mm, 330-2500ml |
φ=50-100mm, H=170mm, 330-2500ml |
Spraying pressure |
0.2-0.25Mpa |
0.2-0.25Mpa |
0.2-0.25Mpa ³ |
0.2-0.25Mpa |
Motor power |
2.2kw |
2.5kw |
3kw |
5.5kw |
Stainless steel |
SS304 |
SS304 |
SS304 |
SS304 |
Electric voltage |
380V50Hz |
380V50Hz |
380V50Hz |
380V50Hz |
PLC |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Frequency converters |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Touch screen |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Mitsubishi |
Circuit contactor |
Siemens |
Siemens |
Siemens |
Siemens |
overall dimension |
2400*1600*2500 |
2500*1800*2500 |
3100*2300*2800 |
3800*2800*2900 |
Weight |
2500kg |
3500kg |
4500kg |
6500kg |
Mineral Water Bottle Filling Machines
