Calcium Reactor

Calcium Reactor photo-1
US$ 2,100 - 12,300 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Automatic Grade:
Automatic
Type:
Reaction Kettle
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Automatic Grade Automatic
Type Reaction Kettle
Place of Origin Zhejiang, China
Brand Name HH
Model Number Calcium Reactor
Voltage made to order
Power(W) made to order
Dimension(L*W*H) made to order
Weight made to order
Certification CE
Warranty 1 YEAR
After-sales Service Provided Engineers available to service machinery overseas
 Product Description
Calcium Reactor 's Suitable Material

Calcium Reactor  is widely used in medicine, building materials, chemicals, paint, resin, food, scientific research and other units used to complete the sulfide, nitration, hydrogenation, alkylation, polymerization and condensation process, is to participate in the reaction material mix as the premise, for heating, cooling, and liquid extraction and gas absorption process of physical change all adopt mixing plant are needed to get to the good effect.


Calcium Reactor
Calcium Reactor ’s Characteristics

1.The pot body and parts in contact with the materials adopt OCr18Ni9 or 1 cr18ni9ti stainless acid-resistant steel plate;


2. Low investment, fast production and high efficiency;


3. Quick heating, high temperature resistant, corrosion resistance, health, pollution-free;


4. Heat transfer effect is better than the enamel reaction kettle, fast heating and cooling.

Calcium Reactor 's Material and Structure
The Calcium Reactor material from Hangzhou Huihe Machine Facture Co., Ltd usually is SUS304 or SUS316L if the customer has no special requirements.



Calcium Reactor ’s Detailed Picture


Calcium Reactor ' s Technical Parameter

Volume (L) Electric power Inner pot diameter(mm) Jacketed diameter(mm) Reducer Model Motor n/KW Stirring speed r.p.m
50 4×2 KW φ400 φ600 BLD 0.8-1 1450/0.8 60-100
100 6×2 KW φ500 φ700 BLD 1.1-1 1450/1.1 60-100
300 6×3 KW φ800 φ1000 BLD 2.2-2 1450/2.2 60-100
500 9×3 KW φ900 φ1100 BLD 3-2 1450/3 60-100
1000 12×4 KW φ1200 φ1400 BLD 4-3 1450/4 60-100
2000 15×5 KW φ1400 φ1600 BLD 4-3 1450/4 60-100
3000 15×6 KW φ1600 φ1800 BLD 5.5-3 1450/5.5 60-100

Notes:

2. Process parameters that need provided: volume, the nature of material, working pressure, temperature, specific requirements, etc.

3. The jacket working pressure≤ 0.09Mpa, also can be made according to customers’ requirements.

4.My skype: amy.tian90
 Our Services
Why Choosing Our Calcium Reactor

1. Huihe machine have sales department, engineering department, after sales department, we are all service for you;

2. We are not competing for the price but the high quality and friendly service we competition

3. The salesman and engineer will listen to your requirements and the effect which you want to reach patiently, and tailored for you;

4. The after sales colleague will service for you from place an order to the actual production;

5. 9 years of industry experience, industry leader;

6. Factory, office site visit.

Calcium Reactor

 Packaging & Shipping
Calcium Reactor ’s Packing Before Delivery
 Company Information
Authentication certificate and strength show

Hangzhou Huihe Machine Facture committed to design and manufacture all kinds of stainless steel container.



We can design according to customers' requirements for various kinds of stainless steel vessel, jacketed kettle, autoclave, milk cooling tank,and fermentor,etc .



The equipments conform to the sanitary standards, thus effectively guarantee people's health.


Calcium Reactor

Huihe Company not only has a professional oversea sales team , but also has department of networks, sales Support and technology research and development,etc .We can supply turn-key project for design and manufacture of a whole production line, for example milk production line, juice production line ,tea production line ,etc.

Our core value is “service for small and medium food enterprises, and benefit of the public”, the products has been send to all over the world for 9 years . We are deeply trusted by the users in the food and beverage industry. We are famous in the food machine field for jacketed kettle, sterilization equipment, reaction tank and fermentation tank ,etc.

Calcium Reactor

Since founded in 2005 , we service customers with good pre-sales support and after-sale service . We purpose is "guaranteed quality, complete variety , competitive price , timely delivery" .We insist our vision “Honest, pragmatic and win-win ” to provide best quality and service.
