Fermentation Tank is used for mechanical mixing and fermentation of matters. This equipment adopts internal circulation to disperse and smash air bubbles by mixing oar, fast dissolving oxygen, good in mixing effect. The tank body adopts SUS304 or SUS316L stainless steel. The tank inside is equipped with automatic sprinkle-nozzle to ensure production process conforms to GMP standard.
It is mainly composed of tank body, mixer, baffle plate, air distributor, cooling tube (or jacket), de foaming machine, manhole cover, integrated visual mirror and lamp etc.
Volume | Height of the whole tank (mm) | Height of the Tank Body (mm) | The Diameter of the Tank Body (mm) | Height of the Discharge Hole (mm) |
500L | 1725 | 800 | Φ850 | 350 |
1000L | 1950 | 900 | Φ1100 | 350 |
2000L | 2500 | 1300 | Φ1300 | 400 |
3000L | 2800 | 1500 | Φ1500 | 400 |
5000L | 3100 | 1650 | Φ1800 | 400 |
6000L | 3350 | 1800 | Φ1900 | 450 |
8000L | 3600 | 1950 | Φ2100 | 450 |
10000L | 3800 | 2000 | Φ2300 | 500 |
20000L | 5350 | 3400 | Φ2600 | 500 |
