We design all kinds of stainless tanks. They are in reasonable design, advanced technology, automatic control and reach GMP standards. The tank adopts vertical or horizontal and single-layer or double-layer structure and adds heat insulator according to the requirements of customers. The inner layer is be polished to Ra0.45μ M and the outside surface adopts mirror or frosted plate to keep warm. There are water inlet, reflux inlet, sterilizing inlet, cleaning inlet, manhole cover and 0.45μ M air respiratorresuscitator.
Volume | Height of the whole tank (mm) | Height of the Tank Body (mm) | The Diameter of the Tan Body (mm) | Height of the Discharge Hole (mm) |
500L | 1725 | 800 | Φ850 | 350 |
1000L | 1950 | 900 | Φ1100 | 350 |
2000L | 2500 | 1300 | Φ1300 | 400 |
3000L | 2800 | 1500 | Φ1500 | 400 |
5000L | 3100 | 1650 | Φ1800 | 400 |
6000L | 3350 | 1800 | Φ1900 | 450 |
8000L | 3600 | 1950 | Φ2100 | 450 |
10000L | 3800 | 2000 | Φ2300 | 500 |
20000L | 5350 | 3400 | Φ2600 | 500 |
