Condition New
Mixer Type Homogenizer
Product Type Paint
Application Liquid with Suspended Solids
Additional Capabilities Other, mixing
Place of Origin Zhejiang, China
Brand Name HH
Model Number GJB
Max. Loading Capacity 1000L
Voltage made to order
Power(W) 7.5KW
Dimension(L*W*H) 500*500*5~3000*3800*12
Certification CE Certificate
Warranty 12 monthes
After-sales Service Provided Engineers available to service machinery overseas

The high pressure homogenizer is widely used in food, dairy products, beverage, medicine industry, refining chemical industry and biological technology.

As a high-press transfer pump.

The liquid change the powder after through this equipment to produce high press and pass the spraying drying, it is the important equipment for powder production.

It can use in other liquid homogenize, high-press transfer and high-press spray area.

Compare with the same products, it has more advantages such as grace and useful structure, convenient operation, easy mending, easy equipped and separate, safety, etc.

 Structure

It is made of machine body, transfer box, pump body, pressure watch, homogenizer, etc.

Vertical equipment, the motor equipped in the machine body, transfer box equipped up the machine body, pump body connect with the transfer box. Motor---belt---transfer box wheel shaft---big wheel shaft, the shaft through the connected band to bring the piston do up and down sport. The piston worked in the pump body form the extraction and press, then through the connection valve control the liquid form the pressure.

Use it as homogenize, should equip with homogenize machine, at this time, the liquid pressed into homogenize machine, through the special homogenize valve, the liquid is homogenize completely.

Parameter

Mode

Rate of flow L/H

Maximumpressure(MPa)

Rated pressure

(MPa)

Motor power(KW)

Dimension(MM)(length*width*height)

GJJ-0.2/25

200

25

20

2.2

755*520*935

GJJ-0.3/25

300

25

20

3

755*520*935

GJJ-0.5/25

500

25

20

4

1010*616*975

GJJ-0.8/25

800

25

20

5.5

1020*676*1065

GJJ-1/25

1000

25

20

7.5

1100*676*1065

GJJ-1.5/25

1500

25

20

11

1100*770*1100

GJJ-2/25

2000

25

20

15

1410*850*1190

GJJ-2.5/25

2500

25

20

18.5

1410*850*1190

GJJ-3/25

3000

25

20

22

1410*960*1280

GJJ-4/25

4000

25

20

30

1550*1050*1380

GJJ-5/25

5000

25

20

37

1605*1200*1585

GJJ-6/25

6000

25

20

45

1671*1260*1420

GJJ-8/25

8000

25

20

55

1671*1260*1420

GJJ-10/25

10000

25

20

75

2725*1398*1320

GJJ-12/25

12000

25

20

90

2825*1500*1320

GJJ-0.3/32

300

32

25

4

1010*616*975

GJJ-0.5/32

500

32

25

5.5

1020*676*1065

GJJ-0.8/32

800

32

25

7.5

1100*676*1065

GJJ-1/32

1000

32

25

11

1100*770*1100

GJJ-1.5/32

1500

32

25

15

1410*850*1190

GJJ-2/32

2000

32

25

18.5

1410*850*1190

GJJ-2.5/32

2500

32

25

22

1410*960*1280

GJJ-3/32

3000

32

25

30

1550*1050*1380

GJJ-4/32

4000

32

25

37

1605*1200*1558

GJJ-5/32

5000

32

25

45

1605*1200*1585

GJJ-6/32

6000

32

25

55

1671*1260*1420

GJJ-8/32

8000

32

25

75

2725*1398*1320

GJJ-0.1/40

100

40

35

3

755*520*935

GJJ-0.3/40

300

40

35

5.5

1020*676*1065

GJJ-0.5/40

500

40

35

7.5

1100*676*1065

GJJ-0.8/40

800

40

35

11

1100*770*1100

GJJ-1/40

1000

40

35

15

1410*850*1190

GJJ-1.5/40

1500

40

35

22

1410*850*1280

GJJ-2/40

2000

40

35

30

1550*1050*1380

GJJ-2.5/40

2500

40

35

37

1605*1200*1585

GJJ-3/40

3000

40

35

45

1605*1200*1585

GJJ-4/40

4000

40

35

55

1671*1260*1420

GJJ-5/40

5000

40

35

75

2000*1400*1500

GJJ-6/40

6000

40

35

90

2825*1500*1320

GJJ-0.1/60

100

60

50

4

1020*676*1065

GJJ-0.2/60

200

60

50

5.5

1020*676*1065

GJJ-0.360

300

60

50

7.5

1100*676*1065

GJJ-0.560

500

60

50

11

1100*770*1100

GJJ-0.8/60

800

60

50

18.5

1410*850*1190

GJJ-1/60

1000

60

50

22

1470*960*1280

GJJ-1.5/60

1500

60

50

37

1605*1200*1585

GJJ-2/60

2000

60

50

45

2000*1300*1585

GJJ-2.5/60

2500

60

50

55

2000*1300*1585

GJJ-3/60

3000

60

50

75

2725*1398*1320

GJJ-4/60

4000

60

50

90

2825*1500*1320

GJJ-5/60

5000

60

50

110

2825*1500*1320

GJJ-0.1/70

100

70

60

5.5

1020*676*1065

GJJ-0.2/70

200

70

60

7.5

1100*676*1065



Products  &  Package

laboratory homogenizer
