Product information:
Usage:
The concentrator is applied to the concentration of Traditional Chinese Medicine, Western Medicine, glucose, vintage, starch, oral liquid, foodstuff, as well as to the reclaim of organic solvent in chemical industry and etc. (for instance, alcohol), especially to the vacuum concentration of some heat-sensitive raw materials featuring characteristics of mini batches and great varieties under low temperature.
Features:
1. Alcohol recovery: Large reclamation capacity and the vacuum contraction procedure make it's production capacity 5~10 times of that of the old counterpart and can lower the energy consumption for 30%, featuring little investment and high reclamation profit.
2. Concentraction of liquid material: The device uses the modes of outer-heated natural cycling and negative pressure vacuum evaporation featuring swift evaporation with great concentration ratio of 1.3; the liquid material is concentrated foamlessly under fully sealed state. The liquid medicine after concentration features no contamination and a strong taste of drug. Besides, it is easy to clean the vessel (All you need to do is to open the top head of the heater). The device is easy to operate and it only covers a small land area. The heater and the evaporator use a structure of stainless steel insulating layer. The surface of the insulating layer is treated by sand grinding and surface polishing. All the parts in contact with media are made of high-quality stainless steel, which meets the GMP standard.
Technical Pramaters:
Model |
QN-300 |
QN-500 |
QN-700 |
QN-1000 |
Evaporation KG/H |
70 |
120 |
145 |
195 |
Volume |
300L |
500L |
700L |
1000L |
Jacket pressure |
0.09Mpa |
|||
Vacuum degree |
500-620mmHg |
|||
Heating area |
1.3 |
1.6 |
2 |
2.8 |
Condensation area |
2.4 |
3 |
3.5 |
4 |
Weigh KG |
380 |
450 |
630 |
950 |
Length mm |
1900 |
2030 |
2100 |
2335 |
Width mm |
1100 |
1200 |
1300 |
1520 |
Height mm |
2300 |
2500 |
2600 |
2765 |
