Main Specifications | |
Rated Load Capacity | 1000 kg |
Operating Weight | 2800 kg |
Bucket Capacity | 0.45m³ |
Log Fork Width |
|
Bucket Width | 1415mm |
Dimensions L*W*H(mm) | 5030x1610x2570 mm |
Engine | |
Model | QUANCHAI QC2105 |
Rated Power | 28kW |
Max. Torque | 130Nm |
Operating Specifications | |
Max. Drawbar Pull | 26kN |
Max. Breakout Force | 24 kN |
Hydraulic System Pressure | 16 MPa |
Hydraulic Cycle Times | 7.6 s |
Steering System | |
Steering Angle Left/Right | 36º±1º |
Min. Turing Radius (Over Rear Tire) | 3600 mm |
Min. Turing Radius (Over Bucket ) | 3750 mm |
Transmission |
|
Type | Countershaft power shift |
Speed Gears | F3/R2 |
Axle | |
Brand | XIN DU |
Front Axle | Fixed with calipers |
Rear Axle | Fixed with Osc.frame and calipers |
Brake System | |
Service Brake | Single circuit,Oil Brake |
Parking Brake | Soft-shaft operation,internal expanding shoe brake |
Tires | |
Size | 1000-16 |
Type | Bias-ply |
