Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List

Qingzhou Cater Industry & Trade Co., Ltd.
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-1
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-2
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-3
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-4
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-5
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List thumbnail-6
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-1
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-2
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-3
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-4
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-5
Front End Loader, Hydraulic Pilot 5 Ton Wheel Loader Price List photo-6
US$ 40,800 - 40,800 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
QZCATER
Model Number:
ZL956
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name QZCATER
Model Number ZL956
Place of Origin Shandong, China
Type Front Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 7934*3060*3483mm
Rated Load 5000kg
Certification CE ISO
Warranty 1 Year
After-sales Service Provided No overseas service provided

Specifications

 Rated capacity3m³
 Rated   weight5000Kg
 Operating weight17000Kg
 Max. breakout force172.3KN
 Total time11s
 Max. dump height3098mm
 Dump distance1198mm
 Wheel base3200mm
 Tread2250mm
 Transportation7934*3060*3483mm

Engine

 Model of engineWEICHAI STEYR WD10G220E22 or CUMMINS 6CTA8.3-C215(TIGER1) or 6CTAA8.3-C215(TIGER2)
 PatternTurbocharger, vertical, water-cooled, 4-stroke, direct injection
 Rated power162KW/160KW
 Max. torque860N.m

Torque converter and transmission system

 Model of torque deviceTorque Converter and Gearbox Combination
 Model of torque converterYJSW315-6J01
 Pattern4-element,single stage
 Transmission typeFull-power shift, countershaft type
 Number of gear2 forward,1 reverse
 Max. travel speed40km/h
 AxleXUZHOU
 Main reducer typeArc taper gear, model ration of first grade
 Pattern of wheel side moderationSingle stage planetary

Tire

Tire size23.5-25

Steering system

 PatternFull hydraulic steering system
 Min. turning radius(outside of bucket)7268mm
 Max. turning angle35°±1

Implement hydraulic system

 Implement pumpCBGJ2080
 Displacement250L/min
 System working pressure20.3MPa
 Distribution device modelDF32
 Pilot valve modelDJS

Brake system

 Brake systemAir assisted oil disc on four wheel
 Parking  brakeAir cutting control inner expand hoof
