4 Ton Wheel Loader JGM756

Name: 4 Ton Wheel Loader JGM756
Brand: JinGong
SKU: 141345664
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Brand Name:

JinGong

Model Number:

JGM756

Fujian Jingong Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XIAMEN

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name JinGong

Model Number JGM756

Place of Origin Fujian, China

Type Front Loader

Moving Type Wheel Loader

Dimension(Long * Breadth * High) 7657*2990*3410

Rated Load 5000 kg

Certification ISO

Warranty 1 Year

After-sales Service Provided Engineers available to service machinery overseas

Main specification and equipment:

Operating Weight	16500 kg
Standard bucket capacity]	2.3-3.6 m3
Rated Load	5000kg
MAX-Tractive Force	150KN
MAX-Breakout Force	160KN
MAX-Climbing Angle	26°
MAX-Dumping Height	3100mm
Dumping Reach	1210mm
Overall dimension(L×W×H)	7657×2990×3410mm
Engine
Model	Weichai WD10G220E11
Type	4-Stroke,inline diesel engine,turbo charged direct-injection
Qty of Cylinders-Bore/Stroke	6-φ126X130mm
MAX-Torque	860Nm
Rated Power	162KW(220HP)
Rated Speed	2200r/min
Transmission System
Torque Convertor	Single-phase-elememttwin-turbine torque converter
Transmission	Planet hydraulic
Gear Shift	2 Forwards, 1 Reverse
Service Speed	Forward gear shift011.5km/h Forward gear shift036km/h Reverse016km/h
Front & Rear Driving Axle
Main driving	First gear reduction of helical bevel gear
Wheel reduction	Planet gear transmission of spur gear
Driving type	Four-wheel drive
Wheel base	2900mm
Wheel tread	2240mm
Tyre Type	23.525
Tyre Pressure	0.270.32MPa
Steering System
Type	All Hydraulic Coaxial Flow Amplification Steering System
Steering Angle	35°Each Side
Min-Turning Radius	Outside of bucket6800mm Outside of the rear tyre5890mm
Hydraulic System
System Working Pressure	17MPa
Boom Lifting Time	≤5.5s
Total	≤11.2s
Brake System
Service Brake	Air Over Hydraulic Disc Brake
Parking Brake	Flexible shaft controlled hydraulic disc brake
Fill Capacity
Fuel tank	230L
Hydraulic tank	280L
