Low Price Professional 5T JGM756KN Foton Backhoe Loader
US$ 40,000 - 46,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
jingong
Model Number:
JGM756KN
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chinese Supplier 3 Ton Front Loader JGM737KN Wheel Loader RentalUS$ 23,000 - 28,000MOQ: 1 Set -
3 Ton Front Loader JGM737KN Wheel Loader Service LifeUS$ 23,000 - 28,000MOQ: 1 Set
-
Wheel Loader Tyre Protection Chains JGM767 With Diesel EngineUS$ 62,000 - 68,000MOQ: 1 Set
-
Construction Machine JGM787 Frontend LoaderUS$ 180,000 - 210,000MOQ: 1 Set
-
JGM787 Model 5m3 Bucket 8 Ton Machine Loader 988US$ 185,000 - 210,000MOQ: 1 Set
Condition
New
Brand Name
jingong
Model Number
JGM756KN
Place of Origin
Fujian, China
Type
Front Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
7657*2990*3410mm
Rated Load
5000kg, 5000kg
Certification
CE ISO
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Low price Professional 5T JGM756KN foton backhoe loader
| Operating Weight | 16500 kg |
| Standard bucket capacity] | 2.3-3.6 m3 |
| Rated Load | 5000kg |
| MAX-Tractive Force | 150KN |
| MAX-Breakout Force | 160KN |
| MAX-Climbing Angle | 26° |
| MAX-Dumping Height | 3100mm |
| Dumping Reach | 1210mm |
| Overall dimension(L×W×H) | 7657×2990×3410mm |
| Engine | |
| Model | Weichai WD10G220E11 |
| Type | 4-Stroke,inline diesel engine,turbo charged direct-injection |
| Qty of Cylinders-Bore/Stroke | 6-φ126X130mm |
| MAX-Torque | 860Nm |
| Rated Power | 162KW(220HP) |
| Rated Speed | 2200r/min |
| Transmission System | |
| Torque Convertor | Single-phase-elememttwin-turbine torque converter |
| Transmission | Planet hydraulic |
| Gear Shift | 2 Forwards, 1 Reverse |
| Service Speed | Forward gear shift011.5km/h Forward gear shift036km/h Reverse016km/h |
| Front & Rear Driving Axle | |
| Main driving | First gear reduction of helical bevel gear |
| Wheel reduction | Planet gear transmission of spur gear |
| Driving type | Four-wheel drive |
| Wheel base | 2900mm |
| Wheel tread | 2240mm |
| Tyre Type | 23.525 |
| Tyre Pressure | 0.270.32MPa |
| Steering System | |
| Type | All Hydraulic Coaxial Flow Amplification Steering System |
| Steering Angle | 35°Each Side |
| Min-Turning Radius | Outside of bucket6800mm Outside of the rear tyre5890mm |
| Hydraulic System | |
| System Working Pressure | 17MPa |
| Boom Lifting Time | ≤5.5s |
| Total | ≤11.2s |
| Brake System | |
| Service Brake | Air Over Hydraulic Disc Brake |
| Parking Brake | Flexible shaft controlled hydraulic disc brake |
| Fill Capacity | |
| Fuel tank | 230L |
| Hydraulic tank | 280L |
