2.8 ton construction machine JGM737K electric wheel loader
- 5000 Unit / Units per Month
- Xiamen
Product Details
Condition: | New | Brand Name: | JinGong | Model Number: | JGM737-II |
Place of Origin: | Fujian, China | Type: | Front Loader | Moving Type: | Wheel Loader |
Dimension(Long * Breadth * High): | 7040*2460*3200 | Rated Load: | 3000kg, 3000 kg | Certification: | ISO |
Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
4 ton construction machine JGM737K electric wheel loader
Performance Characteristics
1. The JGM737-II 3 ton wheel loader is designed with ultra long wheel base, the frame with hinged connection in the middle and box-type structure, enabling strong bearing capacity of frame and good working stability of the whole product.
2. The single rocker arm Z-form reversal mechanism working device has large breakout force due to the optimization design with the help of the computer.
3. The centring arrangement for the hinge points allows for small turning radius and overlapped front and rear wheel tracks during the turning, which can effectively prolong the working lifetime of the tyres.
4. The working device of the 3 ton wheel loader can achieve automatic movement to the flat state. The action cycling time is short and working efficiency is high.
5. The integral quenched cutting plate strengthened bucket has higher strength and durability. Its serving lifetime can be enhanced exponentially.
6. The hydraulic system of the product takes usage of single pump flow division technology. It is fuel efficient with good dynamic property.
7. The adoption of the full hydraulic coaxial flow amplifying steering system facilitates handy and flexible steering as well as reliable operation.
8. Configured with the high-level free maintenance accumulator of Johnson Controls, the 3 ton wheel loader works reliably and stably.
Selectable Unit
1. Yuchai YCB125-TII Engine or Dongkang 6BT5.9-C130 Engine
2. Meritor Drive Axle
3. Coal Bucket (2.0m³), Light Material Bucket (2.5m³), Rock Bucket, and Optional Auxiliary Cutting Plate
4. Cooling or the Cooling and Heating Air Conditioner
5. High Dumping Device
6. Device Suitable for Mine
Standard Facility
1. Weichai Deutz Engine
2. Air-over-oil Caliper Disc Service Brake System and Flexible Shaft Manipulating Band Type Parking Brake system
3. Single-stage Single-phase Centripetal Turbine Torque Converter
4. Standard Tyre with the Specification of 17.5-25-12PR
5. 30 Shaft-fixed Power Shift Transmission Gearbox
6. 30 Drive Axle
7. Standard Boom Arm and Standard Bucket
Specification
Item | Parameter | Unit | |
Operating Weight | 10300 | kg | |
Rated Load | 3000 | kg | |
Bucket Capacity | 1.7 | m3 | |
Max. Dumping Height (High Dumping) | 2850 | mm | |
Corresponding Dumping Reach (High Dumping) | 1000 | mm | |
Max. Traction Force | ≥95 | KN | |
Max. Breakout Force | ≥100 | KN | |
Overall Dimension (L×W×H) | 7040×2460×3200 | mm | |
Boom Lifting Time | ≤5.5 | s | |
Total Cycling Time | ≤10.5 | s | |
Wheel Base | 2750 | mm | |
Min. Turning Radius (Outer Edge of Bucket) | 6040 | mm | |
Rated Power | 92 | kW | |
Traveling Speed | Gear I (Forward/Reverse) | 0-7/9 | km/h |
Gear II (Forward/Reverse) | 0-13/29 | km/h | |
Gear III (Forward) | 0-24 | km/h | |
Gear IV (Forward) | 0-36 | km/h | |
Fuel Tank Capacity | 150 | L | |
Hydraulic Oil Tank Capacity | 180 | L |
Specification of High Dumping Product
No. | Item | Standard Bucket | Coal Bucket | Unit |
1 | Bucket Capacity | 1.7 | 2.0 | m3 |
2 | Rated Load | 3000 | 3000 | kg |
3 | Operating Weight | 10457 | 10463 | kg |
4 | Dump Height | 3200 | 3125 | mm |
5 | Dumping Reach | 1080 | 1150 | mm |
6 | Overall Length | 7410 | 7520 | mm |
6 | Min. Turning Radius (Outer Edge of Bucket) | 6220 | 6260 | mm |
Note: Along with the technical progress, the structure and technical parameters of the wheel loader would be improved continuously without prior notice. In the case of sample information doesn't tally with the information of actual product, please take the actual product as standard.
....
