JGM755K Wheel Loader with Log Gripper
2013 JinGong New Type:
Economic type,
More reliable,
More comfortable.
Main specification
| Operating weight | 17200kg |
| Standard bucket capacity | 2.7m³ |
| Rated load | 5000kg |
| Max. climbing angle | 30 degree |
| Standard dumping height | 2580mm |
| Max. dumping height (when equipped with high dumping arm) | 3500mm |
| Dumping reach | 1815mm |
| Overall dimension | 7260*2990*3295mm |
.
Engine
| Model | Weichai WD10G220E21 |
| Type | 4-stroke, inline diesel engine, turbo charged direct-injection |
| Qty of cylinders-bore/stroke | 6-126x130mm |
| Rated power | 162KW |
| Rated speed | 2200r/min |
Transmission system
| Torque convertor | Single-phase 4-elements, Twin-turbine hydraulic torque converter |
| Transmission | Planetary hydraulic shift |
Quick shift equipment:
| Dumping Height | 2580mm |
| Dumping Reach | 1815mm | |
| Min. hold circle diameter | 1200mm | |
| Max. mouth opening | 2250mm |
Optional equipment:
1) Loose material bucket, rock bucket, side-dump bucket, log fork
2) Air conditioning system: cool wind type ,warm -wind type, cool & warm type.
3) Diesel engine:
Shanghai C6121ZG diesel engine, 162kw/2200r/min
forklift loader main feature:
1. Fully hydraulic powered steering with flow-amplified system, Pilot operated control for loader
hydraulic system, power shift and electric shift optional transmission makes convenient and flexible
operating.
2. JINGONG new Z-bar linkage, high breakout force, short hydraulic cycle time, automatic leveling on
any position, and higher productivity.
3. Special quadrant type transmission shaft of construction machinery. Power transmission is more
reliable.
4. Integral new luxury cab, excellent visibility, safety and reliability.
5. EG-TM combination is supported on three points by dual directions, vibration-isolators. Reducing
resonance and fatigue failure of structure.
6. Optimized structure of diesel engine air intake system reduces dust into air filter, prolonging the
durability of the engine and convenience the service of air filter element. Optimized cooling system
drops overall heat balance temperature.
7. Integral operable hood made of compound material reduces noise and vibration, and makes
operation and service more convenient and flexible.
8. Equipped with SHANGHAI, STYRE, or CUMMINS diesel engine, which is of electric starting, electric
stopping and excellent performance and reliability.
Please contact us if you want more information and other types of forklift loader.
