Specification:
Main Specification Data | |
Weight |
25500kg |
Rated load |
21000kg |
Rated power |
162kw |
Max-tractive force |
140KN |
Max-climbing angle |
20o |
Overall dimension (LxWxH) |
8370x3050x3567mm |
Engine | |
Model |
Weichai WD10G220E11 |
Type |
4-stroke, inline diesel engine turbo charged direct-injection |
Qty of cylinders-bore x stroke |
6-126X130mm |
Max torque |
860N.m |
Rated power |
162kw |
Rated speed |
2200r/min |
Fuel consumption per hour |
≤225g/kw.h |
Transmission System | |
Torque converter |
Single-phase 4-element twin-turbine hydraulic torque converter |
Transmission |
Planet hydraulic shift |
Gear shift |
2 forward, 1 reverse |
Speed |
Forward I: 0-11.78km/h |
Forward II: 0-43.95km/h | |
Reverse: 0-16.11km/h | |
Front &Rear Driving Axle | |
Main driving |
First gear reduction of helical bevel gear |
Wheel reduction |
Planet gear transmission of spur gear |
Driving type |
4 WD |
Wheel base |
3950mm |
Wheel tread |
2360mm |
Tyre type |
26.5-25 |
Front tyre pressure |
0.625Mpa |
Rear tyre pressure |
0.475Mpa |
Steering System | |
Type |
All hydraulic coaxial flow amplification steering system |
Steering angle |
35o each side |
Min-turning radius |
Rear outer wheel center:5890mm |
Hydraulic System | |
System working pressure |
18Mpa |
Boom lifting time |
≤8.7s |
total |
≤17.7s |
Brake System | |
Service brake |
Air over hydraulic disc brake |
Parking brake |
Flexible shaft controlled hydraulic disc brake |
Fill capacity | |
Fuel |
230L |
Hydraulic oil |
270L |
Features:
- Adopt long-wheelbase middle articulated frame with perfect stability and flexible maneuverability, adapting to being used under various operating conditions;
- Adopt 26.5-25 tyre with large minimum ground clearance and good passing performance;
- Maintain the characteristics of loader, adopt torque converter interaction for diesel engine output with big traction and adopt simultaneous drive of front and rear wheels with excellent cross-country performance;
- Key link points of the equipment adopt anti-dust structure that prolongs the service life of the bearing pins;
- Adopt dual-pump converging hydraulic technology with system pressure of up to 16 MPa, high efficiency and energy saving as well as powerful power;
- The JGM761F is the special-purpose type of fork, the JGM761F-I and JGM761F-II are dual-purpose type of fork;
- New luxury cab with elastic suspension and two-way damper, featuring spacious view and noise reduction.
Front loader forklift 26 ton
Standard equipment:
.Weichai WD10G220E11 engine
·Twin-turbine torque converter
·Planetary power shift transmission
·ZL60 drive axle
·Flexible-shaft-operated duplex valve:boom&bucket
·Lifting cylinder and tilt cylinder
·Standard boom&bucket
·Press disc brake as service brake
·Maintenance-free battery 2*12v
·Standard tyre26.5-25(36PR for front tyre and 28PR for rear tyre)
·Deluxe ergonomic seat
·AM/FM radio
Air conditioner
Optional equipment:
Diesel Engine:
Hangfa engine 62kw/2200rpm
Shangchai C6121ZG:162KW/2200rpm
....
