2015 Hot sell Jet suction dredger
- 0 per Month
- 2021 Hot newest small 350 1000m3 Cutter Suction Dredger
- Hot Newest Sand Suction Dredging Boat Dredger for Sale Engineers Available to Service Machinery Overseas Customized Provided MAP
- Sand Dredging Machine 2021 Hot Newest Small 12 Inch Cutter Suction Dredger Engineers Available to Service Machinery Overseas MAP
- 2018 Hot newest small 1000m3 Sand Cutter Suction Boat
- Customized small 12 Inch cutter suction river dredging equipment
- 2022 Hot Newest Small 1200m3 Cutter Suction Dredger Manufacturer Sand Pump Suction Dredger Sand Dredging High Gold Recovery Rate
Product Details
Condition: | New | Type: | Other, Jet suction dredger | Power Type: | Diesel |
Dredging Depth: | 12 m | Draught: | 200 cm | Place of Origin: | Shandong, China |
Brand Name: | Yongli | Model Number: | JSD-450 | Dimension(L*W*H): | 25m*6m*2m |
Weight: | 150T | Certification: | ISO9001 | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Item | Specification | Origin | Note |
Total Length
| 25m |
|
|
Hull Width
| 6m |
| Boat deck CCSB |
Hull Depth
| 2.0m |
| Boat deck CCSB |
Dredging depth
| 1.0m —12.0m |
|
|
Main Engine | Type: 12V190ZLC Power:1000kw | JICHAI Engine
| Have main pump |
Spare gnerating set | Power 50KW | WEICHAI Power
|
|
Gearbox
| Speed ratio: 3.5:1 | HANGZHOUFADA | Using for Main pump |
Main Pump
| Type:450WN Suction tube Diameter Φ600mm Discharge tube DiameterΦ450mm | SHIJIAZHUANG
|
|
Water jet pump | 12Inch,high-liftpump |
|
|
Anchor gear | 3pcs |
|
|
suction pump dia | Insid dia600mm |
|
|
Discharge Distance | 200m |
|
|
| 150T |
|
|
Circuitry System
| Have Intelligent weak current control |
|
We will ship the dredger in bulk or use container .
We will send our enginner go to your workplace install the dredger .After that we will offer technical guide for all the time .
