Jet suction gold dredger
1. Introduction
This is jet suction type gold dredger. There are two water jet and sand suction systems on the pontoons. The two sets of systems could work at the same time and thus with a high capacity.
2.Working Principle
After the solids are sucked up, the two screens will separate the gravels/pebbels, tree branches/roots from the sand, and these waste materials will be discharged into river by conveyor belt or chute. The sand which contains gold will go down to the pulsating sluice box or chute with gold carpet. The tailings is discharged into the river or shore by the pump.
3.Technical Specification
| No. | Item | Parameter | Qty | ||||
| 1 | Pontoon | Length:10m.Width:1.5m | 2 sets | ||||
| 2 | Buffering Box | Length:1.5m.Width:1.5m | 2 sets | ||||
| 3 | Pulsating sluice box | Length:3.0m.Width:1.5m | 2 sets | ||||
| 4 | Waste material chute | Length:3m.Width:1.5m | 1 set | ||||
| 5 | Gravel chute | Length:4m.Width:1.5m | 1 set | ||||
| 6 | Diesel engine | Cummins 40kw | 1 set | ||||
| 7 | Sand suction pump | 8 inch | 1 set | ||||
| 8 | Water supply pump | Volume:50m3 per hour | 1 set | ||||
| 9 | Electricity generator | 20kw | 1 set | ||||
jet suction gold dredger
Jet suction gold and diamond dredger for Cameroon customer
Gold dredger
Suction gold dredger
