Knelson type gravity gold concentrator
Introduction to alluvial gravity gold concentrator
YlCC1000 gold concentrator is gravity separation type concentrator. We design and manufacturer this kind of gold concentrator according to Nelson centrifugal concentrator, which is the world class advanced concentrator for gold. The recovery rate of it could only get as high as 90%, but the price is much lower than Nelson one. It separates the gold just by gravity difference between sand and gold and does NOT use any chemical, which is very environmental-friendly. After so many years of manufacturing, we improve it gradually according to our customers' feedback. For example, we improve the inner tank to be changable and the complete unit could work continuously without stopping processing. What's more, we improve the shock mitigation system. Welcome to visit our factory and see the quality of our gold centrifugal concentrator yourself.
Technical specification for alluvial gravity gold concentrator
Type | YL-300 | YL-600 | YL-1000 | YL-1200 |
Capacity(T/Hr) | 2-3 | 15-20 | 40 to 50 | 80-100 |
Power | 2.2kw | 5.5kw | 11kw | 18.5kw |
Water Consumption (m3 per hour) | 2 to 5 | 20 | 50 | 100 |
Net Weight | 0.5T | 1.2T | 4.5T | 8.5T |
Dimension(mm) | 1200x1200x1400 | 1700×1700×1800 | 2300×2300×2300 | 2100×2100×2700 |
Type 300 used for experiment
gold concentrator
Our other gold and diamond recovery equipments
We need to know more about your local working condition in order to offer a best solution for your project.
We would appreciate if you could provide information like the expecting productivity, dredging depth, discharge distance and so on.
That would help to judge what kind of dredger works most efficiently in your environment.
