EC10 Stainless Steel Essential Oil Distill Equipment on Sale

Specifications

Special Design:
1. Steam extraction part is popular with the structure of basket-in-water.

2. Operation part has adopted PLC or touch screen control system, this accords to customer’s demand.

Features:

1. By steam-distillation to reach the extraction of essential oils.

2. Easy operation. One people can operate this Essential Oil Distill Equipment easily.

3. High efficiency. Using indirect heating of heat-transfer oil, it can quickly reach 100°C high temperature under the conditions of cleanness, safety and atmospheric pressure. If required, with vacuum pump, the extraction speed of essential oils will be more faster.

4.Compact structure. It covers only about 1.5 square meter.

1. Brief instruction of Essential Oil Distill Equipment

Essentail Oil Distill Equipment is popular in production of Chinese medicines, health products, Biological drugs, cosmetics and food, it use technology of biological and chemical separation, can extract Plant components efficiently by steam distillation, have good effect in collecting essential oil from plants.

2. Special Design of Essential Oil Distill Equipment

a. Steam extraction part is popular with the structure of basket-in-water Essential Oil Extract Equipment.

b. Our Essential Oil Distill Equipment operation part has adopted PLC or touch screen control system, this accords to customer’s demand.

3. Main Technical Datas of Essential Oil Distill Equipment

a. Power: 4.0kw, 380v/50Hz, Three Phase

b. Volume of Distillation Pot: 10L

c. Heating Area of Extraction Tank: 0.3M2

d. Condensing Area of Condenser: 0.7M2

e. Cooling Area of Cooler: 0.60m2

 f. Vacuum Pressure for Distillation: 0.3mpa

g. Moisture Extraction Temperature: 50~100c

h.  Power Of Electric Heater: 4 kw (Includes Oil Heating System

 i. Cooling From Tap Water

4. Pictures of Essential Oil Distill Equipment

Essential Oil Distill Equipment

200L Essential Oil Distill Equipment

The Show for Temperature Control Cabinet of Essential Oil Distill Equipment

 Detail of Essential Oil Distill Equipment

Oil-water separator of Essential Oil Distill Equipment

Raw meterials of Essentail Oil Distill Equipment

The material of Essential Oil Distill Equipment can be all kinds of plants

Final product of Essential Oil Extract Equipment

If you have any question about Essential Oil Extract Equipment, please feel free to contact us!

 Thank you for interested in our Essential Oil Extract Equipment!
