Nuts and Bolts Making Machines

Name: Nuts and Bolts Making Machines
Brand: Shengli
SKU: 141334014
Availability: InStock

Nuts and Bolts Making Machines thumbnail-1

US$ 10,000 - 50,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

CNC or Not:

CNC

Power Source:

Hydraulic

Contact Supplier Request Quote Chat Now

Huzhou Machine Tool Works Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

CNC or Not CNC

Power Source Hydraulic

Place of Origin Zhejiang, China

Brand Name Shengli

Model Number YF41

Voltage 380 v, 220 v

Power(W) 2.2 - 30 kw

Weight Depend on Detail Model, Depend on Detail Model

Certification CE, ISO

Warranty One Year

After-sales Service Provided Engineers available to service machinery overseas

Application & Feature

A wide variety applications in straightening long shafts and sectional material, press-fitting sleeve parts,bending, embossing and drawing as well as pressing various plastic and powder wares. It can be operated by a handle or a foot pedal, featured with adjustable pressure and stroke,easy control and reliable. Nominal capacity: 100-5000KN

Main Technical Data

Item		Unit	YF41-10	YF41-25	YF41-40	YF41-63	YF41-100	YF41-160	YF41-200	YF41-315
Nominal Force		KN	100	250	400	630	1000	1600	2000	3150
Max.Working Pressure		Mpa	16	25	25	25	25	25	25	25
Stroke		mm	400	500	500	500	500	500	500	800
Throat Depth		mm	250	355	325	325	325	325	325	1000
Daylight	Straightening	mm	460	430	600	550	600	700	720	600
Daylight	Press-in	mm	630	630	770	800	900	1000	1070	1000
Table Size	LR Straightening	mm	1000	1000	1000	1600	2000	2000	2000	3000
	LR Press-in	mm	460	520	600	630	700	750	750	1000
	Front-back	mm	380	570	550	600	600	600	600	800
Table Height above Floor	Straightening	mm	880	910	770	850	1000	1000	1140	1100
Table Height above Floor	Press-in	mm	710	710	600	600	700	700	790	700
Blanking Hole		mm	U 120	Φ 125	U 200	U 200	Φ 200	Φ 200	Φ 200	Φ 200
Ram Speed	Descent	mm/s	63	60	60	55	38	25	24	100
Ram Speed	Return	mm/s	150	110	150	185	120	80	62	80
Overall Size	Front-back	mm	1110	1400	1550	1650	1750	2025	2045	3400
	Left-right		1000/460	670	680	1600/630	2000/850	2000	2000	2290
	Above Floor		2156	2220	2380	2513	2743	2875	3358	4840/4240
Motor Power		kw	2.2	4	5.5	5.5	7.5	11	15	30

1. How to operate your YF41 200 Horizontal hydraulic press ?

Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding.

2. What’s your after-sale service?

Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.

We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.

3. How about your YF41 200 Horizontal hydraulic press quality?

Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 60 countries where there are metal plate industry ,there are Better machines.
