HZJCC Good Quality YF76-1000 Fire Proof Brick Making Machine

Huzhou Machine Tool Works Co., Ltd.
HZJCC Good Quality YF76-1000 Fire Proof Brick Making Machine thumbnail-1
HZJCC Good Quality YF76-1000 Fire Proof Brick Making Machine photo-1
US$ 50,000 - 300,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Shengli
Model Number:
YF76-1000
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Shengli
Model Number YF76-1000
After-sales Service Provided Engineers available to service machinery overseas

Application & Feature



It is designed for a special-purpose of pressing high strength and density fire-proof bricks with straight-side body, 8-point gib guided way and a float pressing movable bolster to obtain quality bricks.



Nominal capacity: 6300 - 20000KN



Brick Specification: Profile 340 x 340 mm   Depth 20 ~ 50 mm







Main Technical Data





ItemUnitMain Technical Parameters
YF76-YF76-YF76-YF76-YF76-1000BYF76-1000CYF76-1600C
400630630A630B(Whole Rack)(Fission Rack)(Fission Rack)
Nominal PressureKN4000630063006300100001000016000
Allowable Working ForceKN6300100001000010000160001600025000
Max. Working ForceKN8000125001250012500200002000032000
Executed StrokeMM500600600600700700700
Stroke TimesMin/Times20131313101010
Min. Closing HeightMM520650650650700700750
Thickness of Workbench PlateMM120180180180200200200
Top Brick Approach RigidityRigidityRigidityRigidityRigidityRigidityRigidity
Top Brick StrokeMM350350350350500500500
Slider Bottom SurfaceFront RearMM635700700700119011901000
Left RightMM635700700700800800900
Workbench SurfaceFront RearMM820920920920120012001250
Left RightMM730820820820100010001100
Overall SizeFront RearMM2110438743874387600053554500
Left RightMM2812469446944694567049005742
HeightMM5155606060606060725072908090
Main Motor Power/QualityKW375555557590132
KG179004150041500435007400085000106000















FAQ ABOUT HYDRAULIC PRESSES



Does welded beam easy deformation?



We treat it with tempering treatment to reduce internal stress.Besides, we also make casting beam.





The oil cylinder is important part,what if it broke?



We use forging cylinder which is forged by one 45# round steel,no welded.The broke rate is almost zero.





What about the electric system?



We use PLC electric control system with less line,easy maintenance and can programmable.





If part of the machine broke,does it easier to buy it in our country?



We can use customer appointed accessories if necessary.





Do you provide after service?



We provide technical service for life.







we are manufacturer of hydraulic press more than fifty years and can manufacture non-standard hydraulic press as your need( such as large worktable,deep slider stroke,multiple cylinder,high speed,double acting...)
