Home > Manufacturing & Processing Machinery > Metallic Processing Machinery > Metal Forging Machinery > 500 Ton Power Press for Sale

500 Ton Power Press for Sale

Name: 500 Ton Power Press for Sale
Brand: Shengli
SKU: 141333460
Availability: InStock

Huzhou Machine Tool Works Co., Ltd.

500 Ton Power Press for Sale thumbnail-1

US$ 20,000 - 80,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

Shengli

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Zhejiang, China

Brand Name Shengli

Model Number HJS32-500

Voltage 220v, 380v, 380 v, 220 v

Power(W) 37 kw

Dimension(L*W*H) 3750x2620x5220 mm

Weight Depend on Detail Model

Certification CE, SGS

Warranty All Life, One Year for Free, All life, 1 year for free

After-sales Service Provided Engineers available to service machinery overseas

FAQ

Where is your company located?

We're located in Huzhou Economic Development Zone, near Shanghai and Hangzhou city.

Applications & Features

The 32 series is designed for general-purposes suitable to a wide variety of plastic material press-works such as bending, flanging, sheet metal drawing, and also for straightening and press-fit in wide applications of plastic, rubber, electric-motor, automobile, ceramic ware, metal product, abrasive material, fireproof material, powder and metallurgy industries. If you intend to use it for blanking and punching, a buffer device should be ordered in addition to eliminate or mitigate compact and noise.

Loaded with a stand-alone hydraulic station and electrical cabinet, optional of three operating modes of adjust(inch), manual and semi-automatic.

Working pressure, speed and strokes of quick and slow descent can be regulated in the specified range to meet the required process. Providing two controls of preset stroke and preset pressure, if you choose the preset pressure, the press executes hold-pressure and delay, auto ram return after pressing action, and providing hold-pressure with motor run or motor stop as option.

Main Technical Data

Item		Unit	YF31-25	YB32-40A	YC32-63A	HJS32-100	HJS32-200	HJS32-315	HJS32-400
Serial Number			YW03	YW043	YW06	GYZ11N2	GYZ12M6	GYZ1242	GYZ11N5
Nominal Force		KN	250	400	630	1000	2000	3150	4000
Eject Force		KN	60	100	160	300	400	630	630
Return Force		KN	110	150	125	160	240	300	350
Max.Working Pressure		Mpa	25	25	25	25	25	25	25
Ram Stroke		mm	250	320	500	630	710	800	800
Eject Stroke		mm	125	150	160	200	250	300	300
Daylight		mm	450	520	800	900	1120	1250	1250
Ram Speed	Quick descent	mm/s	45	55	110	185	200	220	220
	Work		10~24	15~36	9~22	10~24	7.5~18	6~15	7.5~18
	Return		55	105	105	140	150	150	210
Eject Speed	Eject	mm/s	100	150	90	75	95	75	110
Eject Speed	Retreat	mm/s	200	380	220	155	160	130	200
Opening Table Size	Left-to-right	mm	360	450	570	720	930	1260	1300
Opening Table Size	Front-to-back	mm	320	400	500	630	900	1200	1300
Table Height above Floor		mm	750	870	800	860	550	650	710
Overall Size	Lefe-to-right	mm	1100	1240	1850	2010	2360	2840	3600
	Front-to-back		900	1120	1860	1690	2000	2000	2540
	Height above Floor		1900	2260	2910	3490	3830	4340	4640
Motor Power		kw	3	5.5	5.5	11	18.5	22	37

Item		Unit	HJS32-500	HJS32-500	HJS32-630	HJS32-800	HJS32-1000	HJS32-2500	HJS32-4000
Serial Number			GYZ11N6	YZ11P7	GYZ11N7	/	/	/	/
Nominal Force		KN	5000	5000	6300	8000	10000	25000	40000
Eject Force		KN	1000	1000	1000	1250	2000	2500	4000
Return Force		KN	380	570	430	720	1600	2000	4360
Max.Working Pressure		Mpa	25	25	25	25	25	25	25
Ram Stroke		mm	900	900	1000	1000	1000	1000	1000
Eject Stroke		mm	300	300	300	350	450	500	500
Daylight		mm	1500	1500	1600	1600	1600	1600	1700
Ram Speed	Quick descent	mm/s	250	160	250	150	150	150	150
	Work		6~15	8~15	5~12	5~12	5~12	3~5	5
	Return		185	125	165	120	75	74	55
Eject Speed	Eject	mm/s	75	75	75	80	60	50	60
Eject Speed	Retreat	mm/s	160	160	160	160	120	160	100
Opening Table Size	Left-to-right	mm	1400	1980	1900	1880	2000	3000	3500
Opening Table Size	Front-to-back	mm	1400	1600	1600	1600	1800	2500	2500
Table Height above Floor		mm	500	500	500	500	450	450	380
Overall Size	Lefe-to-right	mm	3750	4470	5140	5390	5940	8800	11085
	Front-to-back		2620	2539	2539	2480	3000	3800	6350
	Height above Floor		5220	5107	5570	5535	5400	6640	7088
Motor Power		kw	37	44	36	60	74	81.55	161.33
