2015 Single-Column Straightening & Press-in Punching Machine
- 50 Set / Sets per Month
- Shanghai China
- T/T
You May Like
Product Details
CNC or Not | CNC | |||
Power Source | Hydraulic | Place of Origin | Zhejiang, China | |
Brand Name | Shengli | Model Number | YF41 | |
Voltage | 380 v | Power(W) | 2.2 - 30 kw | |
Certification | CE, ISO, SGS | Warranty | One Year | |
After-sales Service Provided | Engineers available to service machinery overseas | Weight | Depend on Detail Model |
Product Description
A wide variety applications in straightening long shafts and sectional material, press-fitting sleeve parts,bending, embossing and drawing as well as pressing various plastic and powder wares. It can be operated by a handle or a foot pedal, featured with adjustable pressure and stroke,easy control and reliable. Nominal capacity: 100-5000KN
Item | Unit | YF41-10 | YF41-25 | YF41-40 | YF41-63 | YF41-100 | YF41-160 | YF41-200 | YF41-315 | |
Nominal Force | KN | 100 | 250 | 400 | 630 | 1000 | 1600 | 2000 | 3150 | |
Max.Working Pressure | Mpa | 16 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | |
Stroke | mm | 400 | 500 | 500 | 500 | 500 | 500 | 500 | 800 | |
Throat Depth | mm | 250 | 355 | 325 | 325 | 325 | 325 | 325 | 1000 | |
Daylight | Straightening | mm | 460 | 430 | 600 | 550 | 600 | 700 | 720 | 600 |
Press-in | mm | 630 | 630 | 770 | 800 | 900 | 1000 | 1070 | 1000 | |
Table Size | LR Straightening | mm | 1000 | 1000 | 1000 | 1600 | 2000 | 2000 | 2000 | 3000 |
LR Press-in | 460 | 520 | 600 | 630 | 700 | 750 | 750 | 1000 | ||
Front-back | mm | 380 | 570 | 550 | 600 | 600 | 600 | 600 | 800 | |
Table Height above Floor | Straightening | mm | 880 | 910 | 770 | 850 | 1000 | 1000 | 1140 | 1100 |
Press-in | 710 | 710 | 600 | 600 | 700 | 700 | 790 | 700 | ||
Blanking Hole | mm | U 120 | Φ 125 | U 200 | U 200 | Φ 200 | Φ 200 | Φ 200 | Φ 200 | |
Ram Speed | Descent | mm/s | 63 | 60 | 60 | 55 | 38 | 25 | 24 | 100 |
Return | 150 | 110 | 150 | 185 | 120 | 80 | 62 | 80 | ||
Overall Size | Front-back | mm | 1110 | 1400 | 1550 | 1650 | 1750 | 2025 | 2045 | 3400 |
Left-right | 1000/460 | 670 | 680 | 1600/630 | 2000/850 | 2000 | 2000 | 2290 | ||
Above Floor | 2156 | 2220 | 2380 | 2513 | 2743 | 2875 | 3358 | 4840/4240 | ||
Motor Power | kw | 2.2 | 4 | 5.5 | 5.5 | 7.5 | 11 | 15 | 30 |
1. How to operate your YF41 200 Horizontal hydraulic press ?
Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding.
2. What’s your after-sale service?
Better provide oriented after-sales service including the oversea engineers training available and also international dealer center for any emergency guidance.We have established worldwide network to guarantee our timely response for your any demand no matter where are you.
We welcome engineers from your side to learn the technical design and normal maintenance here,this will help your easy in understanding and helpful if you need to be our dealer.
3. How about your Y41 200 Horizontal hydraulic press quality?
Better is a mature brand in CHINA,through our many years research in technology. our design including structure and detailed security and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 60 countries where there are metal plate industry ,there are Better machines.
