Metal Cold Extruding Hydraulic Press Machine

Specifications

1.Cold-extruding metal parts at normal temperature
2.straight-side type and 8-point gib guided way with good stiffness

  The series is designed for extruding cold and hot metal and with all of functions of cold and hot extrusion. Wholly-framed body press type, adjustable 8-fold guide way with high guide accuracy and retaining, stand-alone hydraulic station and electrical cabinet, optional of three operating modes of inch, manual and semi-automatic separately with preset stroke and preset pressure controls. Working pressure and stroke can be regulated in the specified range. With the features of reliability and high efficiency, it's the ideal solution for metal extruding applications.





Main Technical Data:

Item		Unit	HJY61-100	HJY61-200	HJY61-315	HJY61-400	HJY61-500	HJY61-630	HJY61-800	HJY61-1000
Nominal Force		KN	1000	2000	3150	4000	5000	6300	8000	10000
Return Force		KN	160	240	300	510	570	1250	720	1300
Ejecting Force		KN	200	200	400	500	630	630	1000	1500
Max.Working Pressure		Mpa	25	25	25	25	25	25	25	25
Daylight		mm	1000	700	700	805	1000	1250	800	1800
Ram Stroke		mm	600	400	400	500	500	800	500	800
Ejector Stroke		mm	200	200	200	200	200	350	200	400
Table Height above Floor		mm	600	700	700	600	750	800	800	650
Ram Speed	Quick Descent	mm/s	160	160	160	180	150	200	200	140
	Work		10-18	10-18	9-20	12-23	10-20	12-28	12-23	10-20
	Return		150	150	150	130	160	140	200	120
Opening Table Size	LR	mm	620	620	700	850	1000	1200	1060	1600
	FB		580	580	620	850	1000	1200	1350	1400
Overall Size	FB	mm	1750	1800	3000	3330	2400	2712	3855	3100
	LR		2580	2940	2800	4100	3550	3550	5100	6200
	Height above Floor		3470	3870/3490	4395/3765	4925/4315	5140/4550	6588/5818	6203/5480	7950/6350
Motor Power		KW	11	22	30	22x2	22x2	45x2	45x2	55x2
