gold mining ship

Name: gold mining ship
Brand: hengchuan
Price: USD $100,000 - 200,000 / Set

FOB Price

USD $100,000 - $200,000 / Set

1 Set(Min.Order)

Supply Ability 20 Set / Sets per Month
Port qingdao
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Bucket Dredger	Power Type:	Diesel
Dredging Depth:	15 m	Draught:	15 cm	Place of Origin:	Shandong, China
Brand Name:	hengchuan	Model Number:	HCWD, HCWD-100	Dimension(LWH):	164.23.8
Weight:	20 tons	Certification:	ISO9001, Onsite Check	Warranty:	one year
After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

.Contract packaging.

Product Description

bucket chain gold dredger

Product Description

Short Introduction

1 mining dredger consists of mining system , sifting system and separating system . Used for mining and separating heavy particles ,like alluvial gold, wolfram , Stannum , etc .

2 Requirement : The content of sticky clay , big gravels and stones should be less than 30% and the stone size should be smaller than 100mm .

3 According to requirement , can equip Nomal sluice , Pulsating , jigging sluice , STL Centrifugal Concentrator , etc . If the deposit contain magnetic sand , can also equip magnetic separator .

4 Dredging depth and capacity can be customized . Recovery rate higher than 90% .

Main technical parameters

Modle	Bucket amount	Dredging depth m	Capacity	Ore size mm	Recovery
HCWD-40	40-60	1-5	50-100	≤300	≥90
HCWD-60	60-80	1-8	50-100	≤300	≥90
HCWD-80	80-95	1-10	50-100	≤300	≥90
HCWD-100	100-110	1-15	50-100	≤300	≥90

The work flow

Mineral material by the loader (excavator) feeding on the feeder, feeder evenly by feeding on the washing tank, the high-pressure water washing tank washing with mineral material invibrating screen, enter the automatic washing machine 0.6cm, 0.6-1cm mineral materials ingrading sieve clean into the selected large particles gold particle equipment, mineral materialabove 1cm clean the back to go. Mineral 0.6cm following into the automatic washing machine,automatic washing machine to the muddy water, light sand, further selection of heavy minerals, the automatic washing machine to select gold machine is the last step of theselection of equipment, two sets of gold refining machine. Automatic washing machine of tailings discharged into the fluctuation chute last step scavenging.

System component.

1, mining system: by dredging bucket, chain, water under the arm, upper and lower fourangular wheels, driving force, the main reducer, a main frame. Mainly used for topsoil and mineral extraction operations.

2, processing equipment: the rolling cylinder sieve screening, choose the combination of gold,gold chute and bucket washing machine (roughing equipment), jig (selection of equipment),for the completion of the wash mine ore, ore dressing, broken, screening, conveying,roughing, such as selection of operation.

3, tailings disposal system: belt conveyor, chute, motor, speed reducer, for the abandoned gravel and tailings.

4, water and mineral sand conveying system: water pump, pipes, combined chute and bucket.For water and sand transport.

5, the winch system: from the big arm winch, anchor winch rope winch, bow, sliding winchesetc., into the ship, ship, for horizontal vessel, ship and underwater arm lifting and the liftingoperation.

6, Longmen: a channel, angle iron, iron block, etc., for the catamaran is connected and fixed,underwater arm lifting lifting operation.

Packaging & Shipping

Our products will be based on the actual product size to customize the appropriate means of transport and transport mode, can also according to need to choose the mode of transportation by sea land can be. My door is generally exported from Qingdao products, butalso can choose the appropriate port according to your needs.

Our Services

We also support below services:
1). Training & after-sale service
Training FREE to every customer. Such as: installation, maintenance. And we support 1 year warranty to make sure your machine runs consistently and keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

2). If you are new for this kind of business, I will help you
Many thanks for your trust; we can provide you with the pre-services of design flowchart for complete production lines, spot inspection and operator training according to your requirements and the conditions of applied spot, we can help you choose the most suitable equipment, drilling rig, loader, trucks,excavators and so ongold gravity separator.

Company Information

Company profile

Shandong Hengchuan Ore Machinery Co. , Ltd, established in 2002, is leading ore machinery in china. Company covers area of 20000 square meters.

Our main products :Placer Gold Mining Machine ,Magnetic Separator ,Sand Mining and Washing Machine, Mining Dredgers ,Sand Barges, Particular Vessels, etc. They have been sold not in domestic market, but export to more than thirty foreign countries, like Philippines, Malaysia, North Korea , Mongolia, Cameroon, South Africa, Ghana, Brazil, etc.

Company qualification.

FAQ

Q1. Are you have a manufacturer or trading company?
A:We have the equipment manufacturing plant.. All process finished in our plant, welcome to visit us at any time!

Q2. Where is your factory located? How can I visit ?
A: Our factory is located in mihe qingzhou County,, Shandong Province, China.
You could fly to qingdao Wall Jinan Airport and Qingdao Airport or other airport of China. Then we will pick you up to our factory.

Q3. What is your MOQ of each item?
A: 1PC, OEM is also supported.

Q4. May I know more infomation about your product?
A: Yes, please visit us at www.hcchina.en.china.cn

Q5: What is the lead time?
A: Based on contract.
Usually, 7-30 days after deposit confirmation, it will be based on different machines.

Q6: What is your loading port?
A: Qingdao or based on your requirements.

Q7. Why choose you as supplier?
A: 1. High quality & most competitive price
        We are a factory who could provide the lowest price to you.
        We are top 3 and with more than 20 years experiences in mining equipment.
   2. Fast delivery--Goods will be shipped within 7 - 30 days based on order quantity.
   3. Best service--Replying emails and solving questions timely. Delivery and update information on time.

Contact Us

Name	Yellow Science Yellow
Website	www.hcchina.en.china.cn
Company Name	Shandong Hengchuan Ore Machinery Co.;Ltd
Address	Mihe Industrial zone,Qingzhou City,Shandong province

Company Profile

Qingzhou Hengchuan Ore Machinery Co., Ltd.

Qingzhou Hengchuan Ore Machinery Co.,ltd,was established in 2002,a leading ore machinery manufacturer in China,covering an area of 20000 square meters,have 6 engineers,20 technicians and 100 workers.
Our main products:Gold Mining Machinery,Magnetic separators and all kinds of mining dredger etc.Our main market is domestic,Africa and Southeast Asia,such as Cameroon,Ghana,Mali,Zimbabwe,Malaysia,Indonesia and Philippines etc.
Cutter suction dredger is widely used in dredging engineering.The rotating cutting head in the front of the suction pipe can stir slurry,then dredging pump suck the slurry through the suction pipe,then through the discharge pipe to the mud yards.Dredging, transportation and discharge is a whole series work.So the cutter suction dredger is an efficient and economic dredger.We start to manufacture the cutter suction dredger from 2005,gradually accumulated rich experience in this field.

Development History:
A).Established Magnet Research Institute in 2004,successfully developed the high gradient magnetic separator to 12000-22000GS.
B).Cooperated with Shandong Gold Group and doubled the sales scale.
C).Developed STL-120 gold centrifugal concentrator in 2008.
D).Mature dredger products in 2009.
E).Developed successfylly knelson smiliar type automatic discharge type gold centrifual concentrtor and produced them in large quantity for sellling.
F).Established Shandong Hengchuan International Trade Co.,Ltd in 2015.

Enterprise Spirit -eternal integrity

Enterprise Purpose-to consistently exceed customers' expectations

Core Values-innovation and leading the future

Service Concept- to create value for customers

Development Concept - Quality is life; innovation is the driving force

Corporate Vision- the world leading supplier of magnetic separation equipment
