China manufacturer sand dredger Cutter Suction Dredger for sale
The parameters
Types | HCWNC 150 | HCWNC 200 | HCWNC 250 | HCWNC 300 | HCWNC 350 | HCWNC 450 | HCWNC 500 |
Pump Capacity(m3/hr) | 500 | 800 | 1200 | 2000 | 2800 | 3500 | 5000 |
Dredging Depth | 6.0 | 9.0 | 10.0 | 14.0 | 15.0 | 15.0 | 15.0 |
Full Length | 16.0 | 21.0 | 25.0 | 35.0 | 36.6 | 40.0 | 44.0 |
Hull Length | 12.0 | 14.0 | 18.0 | 25.0 | 26.0 | 30.0 | 35.0 |
Hull Height | 1.5 | 1.6 | 1.6 | 1.8 | 1.8 | 2.2 | 2.4 |
Hull Width | 4.2 | 4.1 | 4.6 | 5.5 | 5.5 | 7.0 | 7.5 |
Engine Power | 200 | 300 | 450 | 720 | 1000 | 1400 | 1600 |
Cutter Diameter | 0.8 | 1.0 | 1.3 | 1.5 | 1.5 | 1.7 | 1.8 |
Suction/Discharge Pipe | 200/150 | 250/200 | 300/250 | 350/300 | 400/350 | 550/450 | 600/500 |
Operation System | PLC Control and Hydraulic System | ||||||
Our advantage
1.Hengchuan cutter suction dredger has a very high cost performance
2.Manufacturing products according to customer's requirements
3.Completely assembled and fully tested before delivery
4.Equiping a perfect operating environment (For instance, air-condition ,toilet and so on)
5.All hydraulic control.
6.Designed as the standard of famous manufacturer in the world.
7.Shuiwang cutter suction dredger is flexible to most kind of geologic structures.
8.Simple operation.
9.Little maintenance and strong power.
10.Cutter suction dredger low price sale
11.Satisfying different work demands.
suction Dredger
The Dredger in building
The customers of us
1. Delivery:
The dredger can be dismounted and transported by bulk ship.
2. Hydraulic Coupler:
The hydraulic coupler can reduce the damage between engine and pump
when emergency.It can reduce the mechanical friction when the engine starts or stops
3. Spud System:
The spuds are made of 16 Mn which makes the spuds stronger.
The diameter is 510mm.
4. Welding Check:
All the welding job is checked by Welding Failure Detector.
5. Cabin:
The cabin adopt creative design: 360 degree view, double layers for anti-hot function,.
6. Anti-rust System:
The surface of the dredger are painted four layers, with China best marine paint from Haijian(brand name).
The hulls are equipped with zinc anode.
7. Installation:
We send engineers to install the dredger and train the workers for the customer, until the satisfaction
of the customer.
8. Warranty:
We supply one year warranty for the main equipment of the dredger and supply all the spare parts
and aftersale service in the warranty time.
Company qualification.
Trade terms of gold refining machine:
Payment details
| Usually paid by T/T or L/C |
By T/T 30% deposit and balance before shipment. | |
We will send the goods picture to you once commodity ready. | |
Packing details | By LCL or FCL(20'/40'GP) container. |
LCL with steel support seaworthy packing | |
Export software scientifical loading work | |
Shipment details | Sea and air shipment available |
MSK / MSC/ APL/ EMC/ WANHAI /KLINE | |
We will send the shipping notice to you once goods loading. |
Contact Us
Name | Andy |
Website | www.hcchina.en.china.cn |
Company Name | Shandong Hengchuan Ore Machinery Co.;Ltd |
Address | Mihe Industrial zone,Qingzhou City,Shandong province |
