Thanksgiving Feedback Price 40t Heavy Mining Dump Truck
More detailed information about this truck:
MAIN DESCRIPTION |
| |||||
Overall Dimension | 8852×4523×4556 (L*W*H) |
| ||||
Payload | 60ton | Dead Weight | 34250kg |
| ||
Front Overhang | 1800mm | Rear Overhang | 3295mm |
| ||
Wheelbase | 1800mm+3800mm |
| ||||
CHASSIS |
| |||||
Brand & Model | WD12.375 |
| ||||
Axle& Driving Type | FAST, 3 axles, driving type 6x4 |
| ||||
Cab | SD70, left or hand drive, air-conditioner, |
| ||||
Engine and Power | diesel engine, 430hp, 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, Euro II emission standard |
| ||||
Traversing Mechanism | Allison 4500, turning system pressure 18MPa | |||||
Gear Box | HW28507T, 6 forward speeds and 1 reverse |
| ||||
Clutch | Model: φ430, Single-plate dry clutch |
| ||||
Tire | 14.00-24, 13units including 1 spare tire |
| ||||
CARGO BODY |
| |||||
Inside Dimension | 5800mm*2800mm*1500mm(L*W*H) |
| ||||
Hydraulic Jack | Front setting telescopic jack |
| ||||
Steel Sheet Thickness | Floor 16mm, front wall 10mm, side and back wall 8mm |
| ||||
Tailgate | One-piece tailgate with upper articulation, safety lock system |
| ||||
