Help CenterHOT 30cbm 8*4 SHACMAN Trucks for Sale
Related Products
-
Popular 6*4 SHACMAN Tractor Truck BlueUS$ 30,000 - 370,000MOQ: 1 Unit -
Popular 6*4 SHACMAN Tractor Truck RedUS$ 30,000 - 370,000MOQ: 1 Unit
-
40t 6*4 SHACMAN Tractor Top ThreeUS$ 30,000 - 370,000MOQ: 1 Unit
-
40t 6*4 SHACMAN Tractor Top SaleUS$ 30,000 - 370,000MOQ: 1 Unit
-
40t 6*4 SHACMAN Truck Hot SaleUS$ 30,000 - 370,000MOQ: 1 Unit
Specifications
trucks for sale1. MAN technology
2. Comfortable four suspension Cabin
3. Weichai Euro II engine
4. FULLER transmission
trucks for sale
1. MAN technology
2. Comfortable four suspension Cabin
3. Weichai Euro II engine
4. FULLER transmission
Model |
SX3316DT366 |
Drive type |
8×4 |
Weight |
|
Complete kerb mass (kg) |
14780 |
GVW (kg) |
31000 |
GCW (kg) |
40000 |
Dimensions |
|
Max.length(mm) |
8875 |
Max.width(mm) |
2490 |
Max.height(mm) |
3450 |
Front / Rear overhang (Chassis) |
1525/2123 |
Wheel base(mm) |
1800+3575+1400 |
Track width(mm) |
20361860 |
Performance |
|
Max.speed (km/h) |
80 |
Approach / Departure angle (°) |
16/33 |
Engine |
|
Brand |
WEI CHAI |
Model |
WD12.375 |
Power(kw/HP) |
276/375 |
Max.Torque (N.m )/rpm |
1300~1600 |
Displacement (L) |
11.596 |
Emmission Standards |
Euro II |
Transmission |
|
Brand |
FAST |
Model |
12JSD160T |
Control type |
Manual |
Gear Shift |
12 forward and 1 reverse speeds |
Clutch |
|
Type |
Single plate,diaphragm spring |
Diameter (mm) |
φ430 |
Action |
mechanical type,hydraulic and pneumatic operation |
Brakes |
|
Type |
Drum |
Service brake |
With dual-circuit compressed air brake |
Park brake |
Power spring brake acting on rear wheel |
Auxiliary brake |
WEVB |
Option |
ABS |
Steering |
|
Type |
Integral circulating ball power sreering |
Option |
ZF8098 |
Chassis |
|
Type |
Ladder structure, widened and cross-section variable |
Suspension |
|
Front Suspension |
Longitudinal leaf spring |
Rear Suspension |
Inverted leaf spring stabilizator suspension |
Axles |
|
Brand |
MAN technology |
Front axle |
7500kg |
Rear axle |
16000kg(each) Double reduction driving axle with inter-wheel differential and differential lock. |
Ratio |
45.92 |
Option |
|
Tyres |
|
Type (Standard) |
12.00-20 |
Option |
12.00R20/11.00-20/11.00R20/12R22.5 |
Fueltank |
|
Tank capacity (L) |
380 |
Material |
Metal |
Electrics |
|
Type |
24V |
Starter |
6.2kw(24V) |
Generator |
2.2kw(28V 80A) |
Battery |
2×135Ah |
Cab |
|
Type |
MAN F2000, Mid-lengthened flat roof |
Equipments |
2 rear window,mechanical clerestory,4 point air suspension,A/C,air suspension driver seat with handle and seatbelts,two sleeping bed,hydraulic reversal cab,with USB can play radilo with MP3 format |
Option |
electric windows,electricity heated, GPS or CD,rear-view mirror,Tachograph;carPhone;electricity reversal cab |
Other |
|
Platform Dimensions (mm) |
7600*2300*1500 |
