Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Concrete Machinery > HZS150 Concrete Batching Plant
HZS150 Concrete Batching Plant
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
CANMAX
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HZS90 Concrete Batching PlantNegotiableMOQ: 1 Set -
HZS75 Concrete Batching PlantNegotiableMOQ: 1 Set
-
HZS50 Concrete Batching PlantNegotiableMOQ: 1 Set
-
HOLD Truck-mounted Line Concrete Pump HDL5131THB(electrical Type)NegotiableMOQ: 1 Set
-
Truck-mounted Line Concrete Pump HDL5131THBNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Shanghai, China
Brand Name
CANMAX
Model Number
HZS150
Specifications
HZS150 Concrete Batching Plant:1.the first class of China
2.Power 55*22 kw
3.Productivity 150 m3/h
4.Model of mixer JS3000
HZS150 Concrete Batching Plant
Key Specifications
Productivity: ≥ 150 m3/h
Mixing time: 60 s/batch
Maximum diameter of principal material: 80/60mm
Unloading height: 3,800mm
Configurations:
Mixing System: JS3000 Twin Shaft Concrete Mixers
Aggregate Bins: PLD4800
Aggregate Feeding: Belt Conveyor
Water System
Compressed Air System
Cement Silo
Cement Screw Feeder
Luxury Control Cabin
Products Certificate: TUVRheinland CE , ISO9001:2000
After-Sale Service:
- Erection and Commissioning
- Operator Training
- Spare Parts Supply
PARAMETER
| Model of water supply system of water pump | IS80-65-160 | |
| Power of motor kW | 7.5 | |
| Model of additive supply system of pump | FB40-32-20×2 | |
| Power of motor kW | 0.75 | |
| Model of air circuit system of air compressor | W-1.5/7-S W-1/7-S | |
| Power of motor kW | 11/7.5 | |
| The total capability of sand storehouse m³ | 20×4 | |
| Cement silo t | 350×4+200×2 | |
| Electric control system | Manual, automatic 200kinds of concrete match ratio | |
| The total power of installation kW | ~290 | |
| The quality of the complete machine t | ~95 | |
| Over dimensions (L×W×H) mm | 7200×5400×13500 | |
| Model | HZS150 | |
| Model of mixer | JS3000 | |
| Productivity m³/h | 150 | |
| Capability of discharge m³ | 3 | |
| Power of motor kW | 55×2 | |
| Aggregate thickness mm | 40/60 | |
| Weighing system | Form of sand and gravel | Type of single or accumulative |
| Scope of measuring kg | 50~6000 | |
| Precision of measuring | ±2% | |
| Form of power material | Type of single or accumulative |
|
| Scope of measuring kg | 10~2800 | |
| Precision of measuring | ±1% | |
| Form of additive and water | Type of single or accumulative |
|
| Scope of measuring kg | 1~850 | |
| Precision of measuring | ±1% | |
