10m3 Concrete Truck Mixer (Hino)

Name: 10m3 Concrete Truck Mixer (Hino)
Brand: CANMAX
SKU: 141324280
Availability: InStock

US$ 65,000 - 75,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

CANMAX

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shanghai, China

Brand Name CANMAX

Model Number HDJ5250GJBGH (GAC Hino 10m3) mixer

Speed of Mixing Drum 0-14r/min

Outline Dimension 9080* 2500 * 3800

Specifications

10m3 concrete truck mixer (Hino)
1.Gross vehicle weight (kg): 25000
2.mixing tube capacity:10m3
3.Engine: P11C-UJ

10m3 concrete truck mixer (Hino)

Product Name			Guangqi Hino 10m3
Model			HDJ5250GJBGH
Load weight (kg)			11170
Gross vehicle weight (kg)			25000
Dimensions	Length mm		9080
	Overall width mm		2500
	Overall height mm		3800
Mixing tube performance parameters	Mixing tube geometry volume m ³		15.64
	Effective volume m ³ mixing tube		10
	Fill Rate%		64
	Feed speed m ³ / min		≥ 3
	Discharging speed m ³ / min		≥ 2
	Residual rate%		≤ 1.0
	Slump mm		50 ~ 210
	Mixing drum speed (rpm)		0 ~ 17
	Mixing tube angle º		13 º
	Drive system	Gear / pump	Imported parts
		Hydraulic circuit	Closed loop
Water supply system	Water tank capacity L / water supply		500 / Electric Water Pump
Vehicle performance and parameters	Wheelbase mm		3640 +1410
	Maximum speed km / h		90
	Minimum turning diameter m		17
	Clutch		Single, dry, hydraulic servo-pneumatic
	Transmission		8 file forward, mechanical manual
	Drive Type		6 × 4
	Steering		Recirculating ball type hydraulic power
	Brake		Pneumatic double-loop
	Tires		295/80 R22.5
	Chassis		YC1250FS2PM
Engine parameters	Model		P11C-UJ
	Type		Water-cooled direct injection diesel engine
	Number of cylinders and arrangement		Inline six-cylinder
	Total displacement L / kW		352
