25 hp Wheel Tractor
LOVOL TE250E Wheel Tractor
1. The use of a simple floor structure and an external divider is easy for maintenance;
2. The safety frame is optional;
3. The single-acting or double-acting clutch is optional;
4. The various gear configurations, such as 8+2, 8+8, and 16+4 are optional, and the velocity distribution is reasonable to meet different operating needs;
5. The synchronized shuttle shift is optional, and the operation is easy, flexible and reliable;
6. The operations of hydraulic steering, the mandrel cylinder front drive axle are easy and flexible.
| Drive type | 4*2 |
| Overall dimension(L * W * H) | 3210*1475*1860 |
| Wheelbase (mm) | 1616 |
| Track(front/rear) | 1100-1300/960-1460 |
| Track(front/rear) regulating method | Step/stepless |
| Min.Ground clearance(mm) | 335 |
| Min.operating weight (kg) | 1280 |
| Counterweight (max)(front/rear) | 54/124 |
| Gears(forward/reverse/creeper) | 8+2/8+8/16+4 |
| Theoretical speed of each gear(forward/reverse) | 1.72-26.02/2.25-10.39;1.72-26.02/1.61-24.24;0.37-26.02/0.5-10.78 |
Send Inquiry to This Supplier
