22m Articulating Boom Self-propelled Aerial Work Platform

Name: 22m Articulating Boom Self-propelled Aerial Work Platform
Brand: CANMAX
SKU: 141323720
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shanghai, China

Brand Name:

CANMAX

Model Number:

GTZZ22Z

Shanghai Canmax Electronic And Mechanical Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port of China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shanghai, China

Brand Name CANMAX

Model Number GTZZ22Z

Specifications

22m articulating boom Self-propelled aerial work platform
1.Platform height 22.4m
2.Lift capacity 230kg
3.WEIGHT 10350kg

22m articulating boom Self-propelled aerial work platform

MODEL GTZZ 22Z
MEASUREMENTS Metric US
Working height maximum *		24.1m	79ft
Platform height maximum		22.4m	73ft6in
Horizontal reach maximum **		13.1m	43ft
A	Platform length-8ft model	0.76m	3ft
B	Platform width-8ft model	1.83m	6ft
C	Height-stowed	2.82m	9ft3in
D	Length-stowed	10.1m	33ft2in
E	Width	2.48m	8ft
F	Wheelbase	2.6m	8ft2in
G	Ground clearance-center	0.33m	1ft
PRODUCTIVITY
Lift capacity (restricted)		230kg	507lbs
Platform rotation		160°
Jib rotation		135°
Turntable Swing		360°continuous
Turntable tailswing		0	0
Drive speed -stowed		6.3km/h	3.9mph
Travel speed -raised or extended		1.1km/h	0.68mph
Gradeability -stowed		30% 25%
Turning radius - inside		3.0m	9ft10in
Turning radius –outside Turning radius - axle extendeded outside		5.2m	17ft
Controls		12V DC Proportional 12V DC Proportional
Solid tires/Foam filled		33×12-20
POWER
Power source		Cummins B3.3-C60(45kw) Perkins 400 61hp (45.5kw)
Auxiliary power unit		12V DC 12V DC
Hydraulic tank capacity		250L
Fuel tank capacity		100L
WEIGHT *******
2WD		10350kg	22817lbs
STANDARDS COMPLIANCE EN280,JG/T5101,Q/ADZV001-2008
