ZL18F Wheel Loader with V Snow Blade
Manufacturer:Qingzhou Hongyuan Vehicles Co.,Ltd.
ZL18F Wheel Loader major advantages
1.Fully Hydraulic torque converter
2.CE Approved
3.Noise tests of cabin and body
4.New Cabin,Real Rops&Fops
5.Rid control .
6.Dipping Cabin,easy to repair.
7.Floating function.
8.All loaders are designed under European customers' suggestion.
Standard:
Standard Bucket.Euro iii Engine.Wheel reduction axle.LED Work Light.Quick Hitch.Extra Hydraulic Line.Hydraulic Joystick.CE/TUV Certificate.220V Engine Preheater.Video For Backward.Luxury Cabin.E-mark Seat.Adjustable Steering Wheel.Lock For Lifting And Steering Cylinder.Tipping Cabin.Floating Function.Easy-damaged Spare Parts.
Optional equipments:
Electric Joystick.14-17.5 Tire.31.5x15-15 Tire.E4 Lamp.Varta Anti-free Battery.
1.0 Engine Details
(1) Model: Xinchai 498BT(EURO III)
(2) Engine type: In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 37KW
(4) Rated Speed: 2200 r/min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g/kw.h
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.2~1.5MPa
(3) Rated input speed: 2500 (rpm)
3.0 Bucket
(1) Bucket Capacity: 0.8m3
(2) Bucket width: 1800mm
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 36.8KN
(5) Rated Load: 1600kg
(6) Operating Weight: 4175kg
4.0 Overall Dimensions
(1) Overall Length (Bucket on ground position): 5300mm
(2) Overall Height
(a) Ground to Cab Top: 2770mm
(b) Dumping Height: 2700mm
(c) Min. Base to the Ground: 290mm
(3) Overall Width: 1800mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4500mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel drive hydraulic disc brake
(2) Parking Brake: Hand operated
7.0 Tyre
(1) Model:20.5/70-16
8.0 Wheelbase: 2100mm
9.0 Track: 1500mm
