Mini Chinese Wheel Loader ZL10 professional front wheel loaderrts
THE TECHNICAL PARAMETERS OF ZL10A CE CERTIFICATE MINI WHEEL LOADER | |||
Item |
Specifications |
Item |
Specifications |
Rated loading weight |
1000kg |
Operating weight |
2850kg |
Rated bucket capacity |
0.5m3 |
Overall dimensions(LxWxH) |
4750x1500x2530mm |
Bucket width |
1500mm |
Engine model |
CHANGCHAI 385 |
Track base |
1215mm |
Engine type |
In-line arrangement, water cooled, three-cycle diesel engine |
Wheel base |
1985mm |
Engine starting mode |
Electric |
|
Min. turning radius (outside of rear wheels) |
4200mm |
Rated power/Rated speed |
20KW/2200rpm |
Min. Ground clearance |
250mm |
Brake mode |
Four-wheel hydraulic spread-shoed brake |
Dump height fully raised |
2300mm |
Warranty |
12 months after received the goods |
Reach fully raised |
850mm |
Color |
According to the requirements of customers |
Lifting time |
4S |
Tyre type |
8.25-16 |
Hydraulic cycle time |
8S |
Shipping port |
Qingdao port, China |
Max. Tilt angle |
300 |
Packing details |
Nude package, 1Unit/20's GP with disassembled cabin, 3Units/40's HQ |
|
Max. Bucket breakout, lift cylinder |
22KN |
Delivery time |
15 days after confirm the order |
Driving mode |
Four-wheel drive |
Supply ability |
100 units per month |
Packing details:
Nude package, 1Unit/20's GP with disassembled cabin, 3Units/40's HQ container
Shipping details:
Departure port: Qingdao port, China
We can supply some spare parts for free, but we suggest that the customer buy some spare parts.
Established in 2005, Qingzhou Hongyuan Vehicles Co., Ltd is a professional manufacturer and exporter that is concerned with the design, development and production of wheel loaders. We are located in Qingzhou, Weifang, Shandong, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
We have over 100 employees to reach an annual sales figure that exceeds USD 1,000,000, and we are currently exporting 80% of our products worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction. We have successfully studied and developed ZL06,ZL08,ZL09,ZL10,ZL12,ZL15,ZL16,ZL18,ZL20,ZL25,ZL30,ZL36,ZL50,HY610, HY910, HY712 etc. Series mini loader and medium-size wheel loader. We also developed Backhoe loader, Off-road forklift, Dumper. As a result of our high quality products and outstanding customer service, we have exported to Germany, Sweden, Finland, Poland, Norway, Hungary, Austria, Belgium, Netherlands, Estonia, Moldova, Turkey, Iraq, Libya, Uganda, Russia, Japan, Malaysia, Australia, Canada, Brazil, Argentina, Uruguay etc.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking forward to forming successful business relationships with new clients around the world in the near future.
