HY Telescopic Wheel Loader ,Real Manufacturer product!
1 .Main advantage :
(1)Boom max lifting height reach 4.1m ,increase the working scope.
(2) Good articulated structure and axle transmission design improve the pass ability.
(3) Quick coupling system, joystick and buttons makes the operating easy and convenient.
2. Standard configuration:
Rated loading weight 1000kg, with Perkins 404D-22 engine, 220V Engine pre-heater, adjustable steering, new cabin with heater, LED Lights, luxury seat, Electronic control driving, Hydraulic joystick, Quick hitch, Standard bucket, Four-wheel drive, with 12-16.5 Tubeless tyres Lock for Lifting And Steering Cylinder, Easy-damaged Spare Parts.
3.Specification of ZL10F Telescopic loader
| Specification | overall weight(kg) | 3000 |
| L×W×H(mm) | 5900×1700×2650 | |
| rated bucket capacity(m3) | 0.6 | |
| Rated load(kg) | 1000 | |
| Maximum Lifting height (mm) | 4100 | |
| Bucket indicator | Yes | |
| Max. breakout force(KN) | 30 | |
| Engine | Model | Perkins 404D-22(EURO III) |
| Type | In-line arrangement, Water cooling, four-stroke |
|
| Rated power(kw) | 35.7kw | |
| Rated speed(r/min) | 2600 | |
| Transmission system | Model of torque converter | YJ240 |
| Type | single-phase single-stage radial-inward turbine triplex |
|
| Gearbox type | Fixed-spindle power shift | |
| Gear shift | 2 gears ahead,2 gear astern | |
| Hydraulic system | Distribution of work valve | ZL20B |
| Working pump | CBGj1032,CBGq1018 | |
| Steering system | Type | Articulated hydraulic steering |
| Max. turning angle | 27±1° | |
| Min turning radius(mm) | 3000 | |
| Brake system | Brake type | Oil brake(Vacuum booster) |
| Tyres | Standard tyres | 12-16.5 Tubeless tyre |
| Optional wide tyres | 14-17.5 or 31x15.5-15 |
4.Additional accessories:
5.Details for the Telescopic loader:
6.Payment and shipping :
.Delivery time:usually 15 days after deposit.
·Payment term: T/T 30% in advance ,balance upon copy B/L.
·Packing: 1 unit in 20ft container,2 units in 40HQ container.packed with triangle wood and 10mm wire fixed.
·Warranty time:one year from receiving the machine.
·Minimum order quantity:1 unit.
The information above just for you reference ,if you want to know more about our products and have questions about them ,please contact me 24h freely ,I am delighted to serve you . Moreover , welcome to visit our factory in china.
