Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Loader > SHM610 Small Wheel Loader With CE Approved.joystick.quickhitch
SHM610 Small Wheel Loader With CE Approved.joystick.quickhitch
US$ 12,000 - 13,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Hongyuan
Model Number:
SHM610 small wheel loader with CE
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SHM610 Small Wheel Loader With CEUS$ 12,000 - 13,000MOQ: 1 Set -
SHM610 Mini Wheel LoaderUS$ 10,000 - 13,000MOQ: 1 Piece
-
SHM610 Small Wheel LoaderUS$ 12,000 - 13,000MOQ: 1 Set
-
SHM610 Small Loader With CENegotiableMOQ: 1 Set
-
Chinese ce Certificate Mini Wheel Loader High QualityUS$ 12,700 - 13,000MOQ: 1 Unit
Condition
New
Brand Name
Hongyuan
Model Number
SHM610 small wheel loader with CE
Place of Origin
Shandong, China
Type
Mini Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
4530*1500*2500mm
Rated Load
1000kg
Specifications
SHM610 small wheel loader with CE.joystick.quickhitch1)YANMAR engine
2)pilot control
3)Multi-function.
4)CE Certificated
SHM610 small wheel loader with CE.joystick.quickhitch
Machine parameters Bucket capacity |
0.5m |
Rated load |
1000kg |
Movable arm lifting time |
4 second |
Three-item-sum time |
9 second |
Max digging up force |
32KN |
Min. turning radius |
4450mm |
Total weight |
2500kg |
Wheel distance |
1170mm |
Axle-base |
1790mm |
Min. clearance to the ground |
240mm |
Overall dimensions (L*W*H) |
4530mm*1500*2500mm |
Dumping height |
2300mm |
Drive means |
4*4(4WD) |
Diesel engine model |
Yanmar (4TNV-88-BS) |
Rated power |
25.2KW/34.3 hp |
RPM |
2200rpm |
Tire type(Tubeless wider tire) |
12-16.5 |
|
Static hydraulic transmission, expand hoof brake, load sensing full-hydraulic steering
| |
