Help CenterLZ280 Tractor
Negotiable
MOQ: 8 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Wheel Tractor
By wheel:
2WD
Usage:
Farm Tractor
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Type
Wheel Tractor
By wheel
2WD
Usage
Farm Tractor
Certificate
Other
Model Number
LZ280
Place of Origin
Shandong, China
Specifications
18HP to 160HP tractors with canopy,cabin ,power steering, single or dual clutch,Implements such as disc harrow,plough etc.| Model | LZ280 | ||||||
| Type | 2WD Wheeled Type | ||||||
| (mm)Dimensions of Tractor | Length (to front ballast) | 2890 | |||||
| Width | 1470 | ||||||
| Height (to the exhaust vent) | 1900 | ||||||
| Tread | Front Wheel | 1300 Fixed or 1100~1300 Adjusted | |||||
| Rear Wheel | 1300 Fixed or 1300~1350 Adjusted | ||||||
| Axle Base | 1710 | ||||||
| Min.Ground Clearance | 347.5 | ||||||
| Structure weight (kg) | 1040 | ||||||
| Ballast weight (kg) |
Front ballast | 56 | |||||
| Rear ballast | 112 | ||||||
| Rated traction force (kg) | 469 | ||||||
| Engine | Model | 385 | |||||
| Type | Vertical,3-Cylinder,Water Cooled and 4-stroke | ||||||
| Rated Power(kw) | 20.5 | ||||||
| Rated speed (r/min) | 2400 | ||||||
| Fuel | Diesel | ||||||
| Tyre | Front Wheel | 5.00-16 | |||||
| Rear Wheel | 9.5-24 | ||||||
| Clutch | Dual-stage clutch | ||||||
| Steering | power steering | ||||||
| Transmission Type | 8+2 or 8+8 with shuttle gearshift or 16+4 with creeper shift | ||||||
| Suspension Type | 3-point links | ||||||
| PTO | Type and Rev | Semi-independent Type 540/1000 | |||||
| Spline Size | F35 Rectangle Spline with 6 teeth | ||||||
| Structure and specification are subject to change without notice. | |||||||
