Product Description

 Floating Ball Valve

 Product Name:  Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608

Design Standard:API 6D,ASME B16.34,API 608
Body material:WCB,LCB,CF8,CF8M,CF3M etc.
Ball material:13Cr,SS304,SS316,SS316L etc.
Seat material: PTFE,RPTFE,PEEK,NYLON
Class:150LB to 1500LB
Size:1/2" to 10"
Connection:Flanged,welded,threaded
Material:Carbon & Stainless Steel
Pneumatic actuator operation,Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608Pneumatic actuator operation,Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608
Pneumatic actuator operation,Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608
Pneumatic actuator operation,Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608
Design Feature:
·Fire safe and anti-static design. Metal to metal sealing shuts off valve flow when soft sealing materials are destroyed by fire.
·Optional stem extension . Extension stem can meet the customers' demand, to adapt to any condition.
·Secure line flow locking device. Valve is equipped with an integral locking device to secure line flow.
·Anti blow-out stem design. It has a taper on sealing surface, it can be replaced packing when the valve is open.
·Optional operation.Gear,electric or pneumatic actuator is available upon request.
Pneumatic actuator operation,Floating Ball Valve 1/2"-10" API 6D,ASME B16.34,API 608
Size and Dimensions:
Class Dimensions(mm)
NPS(inch) 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3 4 5 6 8 10
DN(mm) 15 20 25 32 40 50 65 80 100 125 150 200 250
150LB L 108 117 127 140 165 178 190 203 229 356 394 457 533
H 59 63 75 86 97 107 142 152 178 252 272 342 345
W 130 130 160 220 220 260 320 320 400 700 1100 1100 *
300LB L 140 152 165 178 190 216 241 283 305 381 403 502 568
H 59 63 75 86 97 107 142 152 178 252 272 342 345
W 130 130 160 220 220 260 320 320 400 850 1100 * *
600LB L 165 190 216 229 241 292 330 356 432 508 559 660 -
H 59 63 75 95 107 162 205 226 240 305 353 374 -
W 130 130 160 220 230 230 400 400 500 850 * * -
  * Gear
