Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D

Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-1
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-2
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-3
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-4
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-5
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D thumbnail-6
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-1
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-2
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-3
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-4
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-5
Stainless Steel Casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D photo-6
US$ 1 - 10,000 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Check
Pressure:
Medium Pressure
Contact Supplier Request Quote Chat Now
Wuxi MSV Import And Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Standard or Nonstandard Standard
Structure Check
Pressure Medium Pressure
Power Hydraulic
Material Casting
Temperature of Media Medium Temperature
Media Oil
Port Size 1/2"-36"
Place of Origin Jiangsu, China
Model Number Check Valve
Brand Name MSV
Application Other, Oil and Gas,Chemical
Product Description
Product Name:Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D
Design Standard:BS 1868,ASME B16.34 ,API 6D
Body material:WCB,LCB,CF8,CF8M,CF3M etc.
Sealing face type:13Cr/13Cr,13Cr/STL,STL/STL,304/304,316/316,316/STL etc.
Class:150LB to 2500LB
Size:1/2" to 48"
Connection:Flanged,welded
Material:Carbon & Stainless Stee
 Stainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6DStainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6DStainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6DStainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D


Stainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D
Stainless Steel casting,Check Valve 1/2" to 36" BS 1868,ASME B16.34 ,API 6D
Size and Dimensions:
Class Dimensions(mm)
NPS(inch) 2 2-1/2 3 4 5 6 8 10 12 14 16 18 20 24 28 32 36
DN(mm) 50 65 80 100 125 150 200 250 300 350 400 450 500 600 700 800 1000
150LB L 203 216 241 292 330 356 495 622 698 787 864 978 978 1295 1448 1727 1955
H 165 175 190 215 240 265 320 365 415 460 495 550 590 650 838 1016 1092
300LB L 267 292 318 356 400 444 533 622 711 838 864 978 1016 1346 1499 1727 2083
H 190 205 220 245 270 295 330 420 480 535 585 615 685 785 889 1016 1143
600LB L 292 330 356 432 508 559 660 787 838 889 991 1092 1194 1397 1600 - -
H 210 230 255 295 335 365 420 505 545 600 650 735 800 965 1066 - -
900LB L 368 419 381 457 559 610 737 838 965 1029 1130 1219 1321 1549 2032 - -
H 225 240 254 279 360 381 533 558 609 736 762 863 939 1066 1193 - -
1500LB L 368 419 470 546 673 705 832 991 1130 1257 1384 1537 1664 - - - -
H 265 240 303 340 380 430 500 605 785 830 950 1080 1145 - - - -
2500LB L 451 508 578 673 794 914 1022 1270 1422 - - - - - - - -
H 285 305 350 410 490 540 620 705 855 - - - - - - - -
