Crawler Hydraulic Tree Spade With CE

Name: Crawler Hydraulic Tree Spade With CE
Brand: hunter
SKU: 141309160
Availability: InStock

Qingzhou Honorsun Heavy Industry Co., Ltd.

US$ 32,500 - 40,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Brand Name:

hunter

Model Number:

DMB-1

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Brand Name hunter

Model Number DMB-1

Place of Origin Shandong, China

Certification CE

Warranty 1 year

After-sales Service Provided Overseas third-party support available

SPECIFICATION FOR TREE TRANSPLANTER

Wheeled model		DMA-1	DMA-2
Total weight(t)		5.2	6
(km/h) Travel speed		0-35	0-35
(L) Fuel tank volume		100	100
(L) Hydraulic oil tank volume		100	100
Engine	(KW) Power	42	48
	(rpm) Rotation speed	2300	2300
	(N.m/r/min) Max torque/rotation speed	205/1650	250/1650
Hydraulic system	(MPa) Working pressure	20	20
Working performance	(º) Gradeability in working	10	10
	(º) Max wheel rotation angle	30	30
	(mm) Tree diameter	≤150	240
	(º) Gradeability in loose	25	25
	(mm) Digging soil ball diameter	≤800	800-1200
	(mm) Digging depth	700	850
	(min/unit) Tree moving time/unit	2-4	6-8
	(grade) Soil requirement	1grade	1grade
	(mm/10min) Cylinder inner discharge	≤40	≤40
Overall Dimensions	(mm) Shipping length	4390	4390
	(mm) Shipping height	2275	2275
	(mm) Overall width	1820	1820
	(mm) wheel base	1745	1745
	(mm) Wheel tread	1536	1536
	(mm) Mini ground clearance	244	244

Crawler model		DMB-1
(t) Total weight		6.2
(km/h) Travel speed		2-5
(L) Fuel tank volume		140
(L) Hydraulic oil tank volume		130
Engine	(KW) Power	48
	(rpm) Rotation speed	2300
	(N.m/r/min) Max torque/rotation speed	250/1650
Hydraulic system	(MPa) Working pressure	20
Working performance	(º) Gradeability	70
	(mm) Tree diameter	≤240
	(mm) Digging soil ball diameter	≤1200
	(mm) Digging depth	≤850
	(min/unit) Tree moving time/unit	6-8
	(grade) Soil requirement	1
	(mm/10min) Cylinder inner discharge	≤40
Overall Dimensions	(mm) Shipping length	4200
	(mm) Shipping height	2670
	(mm) Overall width	1960
	(mm) Track gauge	1560
	(mm) Mini ground clearance	260
