Specifications
Hydraulc joystick
Euro type quick hitch
CE arrproved
Euro-3 engine
Fully hydraulic transmation with CVT shift
1.0 Engine Details
(1) Model: Changcai4L68
(2) Engine type:In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power:37KW (50.32H.P.)
(4) Rated Speed:2200 r/p.min (rpm)
(5) Fuel Consumption ratio in standard working condition: 230g/kw.h
2.0 Transmission System
Hydraulic converter + drive shaft + axles
3.0 Bucket
(1) BucketCapacity: 0.65 m3
(2) Bucket width: 1700mm
(3) Bucket type:Heavy-duty bolt on teeth
(5) Rated Load: 1500kg including attachment
4.0 Overall Dimensions
(1) Overall Length: 4320mm
(2) Overall Height:2670mm
(3) Overall Width: 1720mm
(4) Max. lifting Height:4250mm
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4950mm
(3) Driving System: Hydraulic converter, four wheel drive
(4) Quick coupling system
(5) Joystick
(6) Self levering
6.0 Brake System
(1) Service Brake:Four Wheel Chuck brake
(2) Parking Brake:Hand operated
7.0 Tyre
(1) Model:12-16.5, 12ply (2)Width: 307mm(3) Diameter: 831mm
8.0 Wheelbase: 2400mm
9.0 Track: 1345mm
10. system pressure:20Mpa; Hydraulic output:70L/min
