Help CenterExcavator SW120B -12TONS
Related Products
-
China's Best-selling 13 Ton Hydraulic Crawler ExcavatorUS$ 50,000 - 57,000MOQ: 1 Set -
HS75 /Hydraulic Crawler ExcavatorsUS$ 30,000 - 39,000MOQ: 1 Set
-
Hot Sell Hydraulic Crawler Excavator HS135US$ 50,000 - 57,000MOQ: 1 Set
-
HS75 Hydraulic Crawler Excavators With High QualityUS$ 30,000 - 39,000MOQ: 1 Set
-
7 Ton Hydraulic Crawler Excavators With High QualityUS$ 30,000 - 39,000MOQ: 1 Set
Specification
1, with LKC rotary device, hydraulic brake, rotary performance, gentle, effective to extend the service life of rotating equipment.
2-performance supercharged engine, power strong.
3, double-piston variable displacement pump, double pump confluence to achieve composite action, to improve operational efficiency.
4, the hydraulic system configuration overload valve, fill valve, throttle, one-way valve and high pressure filter, to extend the service life of hydraulic components.
Boom cylinder, bucket cylinder rod as a buffer tank, action, soft, extended cylinder life.
5, Parker seal, to ensure the reliability of the hydraulic system; large-capacity radiator, to adapt to continuous operation.
6, four domestic brands along the high-intensity, high reliability.
7, the main structural parts, strengthen the material, to improve the welding process, prolonging life.
8, streamlined cab and expanding driving perspective, sliding front window to improve ventilation. Airline seats, premium sound, air-conditioning, high-count is more user-friendly operation and comfortable environment.
9, configure centralized filling oil installations, maintenance and more convenient.
MAIN PARAMETER
Engine Model LR4A3Z-G63C
Rated power / speed 83kw/2400r/min
Turntable width (Steering width): 2385mm
Tail radius of gyration (Tail turning radius): 2450mm
Gauge (Gage 2010mm
Minimum ground clearance (Min ground clearance 400mm
Hydraulic system pressure (Hydraulic system pressure) 16-28Mpa
Bucket Capacity (Bucket capacity): 0.6m 3
Rotary Speed (Reverse speed): 8r/min
Climbing capability (Grade ability): ≥ 40%
Maximum digging force (Maximum excavating force): 45KN
Digging Distance (Maximum excavating distance): 7300mm
Maximum digging depth (Maximum excavating depth): 4010mm
Maximum digging height (Maximum excavating height): 6020mm
Machine quality (Whole machine mass): 12t n
Pad width (Track link width): 500mm
Walking speed (Travel speed) : 3-5km / h
We can manufacture according your need
