Help CenterPerfect Quality Cutter Suction Dredger With SGS for Export
Related Products
Specifications
cutter suction dredger1.Australia WARMAN Tech pump
2.German Schineider Electric System
3.Cummins engine USA
4 ISO9001
Oversea service provided cutter suction dredger
1.Features
Cutter Suction Dredger is a special dredging machine with ISO9001:2008. Cutter Suction Dredger is flexible to most kinds of geologic structures and has a lot of obvious advantages :
1. Wide application range : It can be widely used for mining, sand production, reclamation construction, desilting, land reclamation and so on.
2. High efficiency: The max output can reach to 700 m³/h, water flow 800-5000 stere per hour, digging depth is 4-15 meters, discharge distance is 200-1500 meters.
3. Quick return, high profits: usually, the investor can Achieve profitability within half a year. It is highly efficient with low cost, a good underwater dredging machine.
4. Standard quality: the main body of the machine is stong, durable and low failure rate.
2.Basic Parameter of different kinds of cutter suction dredger
| Model | KDCSD200 | KDCSD260 | KDCSD300 | KDCSD350 | KDCSD400 | KDCSD450 | KDCSD500 |
| Dredger Body | |||||||
| Dimensions(L*W*H)m | 12.5*4.6*1.4 | 12.5*5.8*1.6 | 14.5*5.8*1.8 | 14.5*5.8*1.8 | 22*6.4*2 | 26*7*2 | 26*7.1*2.2 |
| Engine room(m) | 7.5*2.25*1.4 | 8*2.8*1.6 | 9*3.2*1.8 | 9.5*3.2*1.8 | 12*3.4*2 | 14*3.4*2 | 14*3.5*2.2 |
| Dredging data | |||||||
| Standard dredging depth | 6-7m | 6-8m | 8-10m | 10-12m | 12-14m | 12-14m | 12-14m |
| Pump model | 8/6” | 10/8” | 12/10” | 12/10” | 14/12” | 14/12” | 450WN |
| Water flow | 450m³/h | 800m³/h | 1100m³/h | 1500m³/h | 1900m³/h | 2500m³/h | 3200m³/h |
| Suction pipeline diameter(mm/inch) | 260 | 300 | 350 | 350 | 400 | 450 | 500 |
| Discharge pipeline diameter(mm/inch) | 200 | 260 | 300 | 350 | 400 | 450 | 500 |
| Devices | |||||||
| Total power KW | 176kw | 258kw | 353kw | 480kw | 640kw | 930kw | 1200kw |
| Generator set(kw) | 24 | 24 | 24 | 24 | 24 | 36 | 36 |
| Cutter head | |||||||
| Diameter (mm) | 850-30 | 950-40 | 1100-50 | 1200-80 | 1300-110 | 1500-120 | 1700-140 |
| Winch(hydraulic) | |||||||
| Ladder winches | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-10000 | JC-12000 |
| Swing winch | JC-3000 | JC-4000 | JC-4000 | JC-6000 | JC-6000 | JC-8000 | JC-10000 |
| Spud | |||||||
| Quantity | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| Spuds length*diameter(mm) | 8600*273 | 11000*300 | 13000*350 | 15000*377 | 17000*450 | 17000*550 | 17000*600 |
| Spuds weight/pic | 900kg | 1500kg | 2000kg | 2500kg | 3900kg | 4500kg | 5000kg |
3.Products Display of cutter suction dredger
Product detail: Cutter Head
Product detail: Winch
Product detail: Warman Pump & Cummins Engine
Product detail: Gear Box
Cutter Suction Dredger in work site
Cutter Suction Dredger package detail:
Iron hoop box or bulk packed with container, or packed as your requests.
1.Rational and practical design according to customers' request proved.
2.Within warranty period,we provide free repair if quality problems emerge.
3.Engerneers are avaliable to service oversea to assemble and test the machine according to the contract.
4.Free training of the first batch of operater proved, any question or problem about the products can be answered via online support,phone calls or on-sit support 24 hours.
Qingzhou Keda ore machinery Co.,LTD. is a professional ore machine manufacturer,which is professional to produce mining equipment with ISO9001:2008 and patent. Professional production equipment, sand-excavating pumping iron chosen sand equipment, bait-casting equipment, washing sand gold sand equipment, equipment manufacturing, magnetic separators, crushing machine, etc, and a hundres dozens of products.
Certification
1. Is our company a direct or indirect producer?— Our company is a direct producer.
2. Are our products certified or patented? — Yes, we only provide certified products.
3. Can we offer good after sale service? — Yes, the warranty of all our products is one year and all spare parts will be provided fast and cheap forever.
4.In order to provide you with efficient & suitable quotation and assistance for you, could you kindly tell
me the following information:
1) Output capacity(m3/h)
2) Max.dredging depth(m)
3) Discharge distance(m)
If you have any question about our products or company, please let us know, we will try our best to make you satisfied.
