Watermaster Dredger for Export

Watermaster Dredger for Export photo-1
Watermaster Dredger for Export photo-2
Watermaster Dredger for Export photo-3
Watermaster Dredger for Export photo-4
Watermaster Dredger for Export photo-5
US$ 500,000 - 800,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Comprehensive water operating equipment
Power Type:
Diesel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Other, Comprehensive water operating equipment
Power Type Diesel
Dredging Depth 6.5 m
Draught 150 cm
Place of Origin Shandong, China
Brand Name KEDA
Model Number Water KD-I
Dimension(L*W*H) 11*3.3*3.1m
Weight Approx. 20t
Certification ISO 9001:2008 Quality Certificate
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Water KD-I includes functions of cutter suction, digging, grabbing, piling, weeding etc. as a whole, can be used in shallow areas such as, coastal beach, inland lake, city rivers, channel and reservoir, industrial settling pond, can be used for dredging, reclamation, desilting, weeding and piling etc. Its features are as follows:

1. Disposal easily, no need for crane, can move on a road and get in and out of the water without too much cost;
2. Self-propulsion with propellers;
3. Work stable, with spuds and support legs to keep balance;
4. High efficiency, with submersible mud pump and cutter compound equipment ensuring high slurry density (around 25%);
5. One person operation. Workers with excavator operation skills can operate easily after a little training;

6.Can be used in closed channel, shallow areas, industrial pond, reservoir etc. where other dredgers can not work;
7.Lights on dredger are available to make sure constant work for maximum efficiency.

The basic technical parameter



No.

Name

Specification

Remarks

1

Size(L*W*H)

11*3.3*3.1m



2

Weight

20t





3

Engine

Cummins Made In China



Cooling type

Turbocharged and inter-cooled



Power

194kw (260HP)



Rotation speed

2200r/min



Fuel tank

2000L



Electric system

24V



4

Hydraulic System

Rexroth series Made In China



Axial piston pump A

For dredge pump and propeller



Max. operating pressure

25MPa



5

Excavator

Swinging angle

180º



Bucket cylinder force

80kn



Lifting capacity

at max. reach

22kn



Lifting capacity with Power

Liftat max reach

25kn



6

Stabilizer

Front stabilizer,

max depth

5m



Rear tilting stabilizer,

max depth

6m





7

Hull

8 compartments,corrosion resistant painting outside

and inside,protective skid bars on bottom,slip-safe deck,handrails

8

Operation Room

Adjustable chair,movable side-window,

air condition,PLC system,signal lights and floodlights

Self-propulsion,

speed of 4 knots

9

Optional Equipment

Reamer pump,mud pipe,nozzle,rake,clam shell, vertical pile bucket,

steel sheet pile head,maintenance crane, side pontoon etc.

10

Dredge Pump



Outlet diameter

250mm



Max. dredging depth

6.5m



Max.discharge distance

1500m



Water flow

400m3/h







The Detailed Shows

 Watermaster dredger for exportWatermaster dredger for exportWatermaster dredger for exportWatermaster dredger for export



In working location

 Watermaster dredger for export

Packaging & Shipping





Our Services

1.Pre-sale services: Passion &thoughtful

We provide you with the prophase plan, process flow design and manufacturer equipment according to your special demand.

2.Sale services: Oversea Technicians

Oversea technicians will be sent to the jobsite for guiding the installation training operators and finishing the check and accept together with you.

3.After-sale services: Faithfulness

One year warrantee to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.



Company Information

Qingzhou Keda Mining Machine Co., Ltd is a factory with professional manufacture experience, compared with trading company, we have more advantages as below:

1)competitive price

2)customers can visit our factory and test our machines at anytime.

3)repairing the machine in time.

4)on-time delivery



 Quality Certificates:

 Watermaster dredger for exportWatermaster dredger for export





Our clients

 Watermaster dredger for exportWatermaster dredger for export



You can click the link, it is introduction vedio of our company.

https://youtu.be/uIuRcg6Syxs
