Specifications
(1).Name:CT-C hot air circle Oven(2).Widely used
(3).Easy Flammable and Explosive Material is Forbidden.
(4).GMP
Principle:
The product was upgraded and regenerated for several times and has reached to advanced level both at China and all over the world. It uses steam or electric heater as heating resource and uses axial fan, heat exchanger to heat air in convective way. The laminar flow of hot air passes through the baking trays and will carry out heat transmission with material. Fresh air will enter into the oven from inlet to supply and then discharge from damp outlet. Fresh air is supplied, wet and hot air is discharged continuously. In this way, suitable RH in oven can be maintained. The ultimate advantage of oven is that most hot air is cycled in the oven, it increases heat transmission and saves energy source. It makes thermal efficiency of oven raise from 3-8% of traditional drying oven to about 35-50%. It uses the function of reinforced ventilation to decrease temperature difference from up to low. The oven delivered by our factory is adapted air distribution device. Before application, customer can adjust fan blade in order to make the temperature difference at the best state.
CT series oven is not equipped with automatic control. It adapts 4-72 centrifugal fan. Model CT-C series oven adapts low noise high temperature resistant axial fan and also equips with automatic constant temperature control system, computer control system for customer’s choice.
Explanation:
1. There are four kinds of heating resource for choice: steam, electricity, heat conducting oil, both steam and electricity.
2. The temperature (steam heating): 50-140°C, Max 150 °C
3. The temperature (when using electricity and far-infrared): 50-300°C
4. The automatic control system or the computer control system is selectable.
5. Commonly used steam pressure 0.2-0.8 MPa (2-8kg/cm2).
6. Standard electric heating is 15kw for type CT-1,CT-C-1, easy flammable and explosive material is forbidden.
7. The special requirements should be indicated at the time of order.
8. The price for the non-standard oven should be consulted.
9. If the operation temperature is more than 140°C or less than 60°C, it should be indicated at the time of order.
10. The oven and baking tray made by our factory are uniform in the dimensions, and can be exchanged with each other.
11. Baking tray dimensions: 460*640*45mm
12. Explosive-proof motor and control cabinet as option.
Application
The drying oven is suitable for the material, product hot solidification and drying de-watering in the pharmaceutical, chemical, food, farming industries, side-product, aquatic product, light industry, heavy industry and so on. Such as raw material medicine, crude drug, prepared herbal traditional Chinese medicine, plaster, powder, particle, drinking agent, pill, packing bottle, pigment, dyestuff, de-watering vegetable, dried fruit piece, sausage, plastics, resin, electric component, baking varnish etc.
Technical parameter
